PSDW81642M-A360 - DAHUA DH-PSDW81642M-A360 8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera With 360-degree panoramic view IR distance up to 400 m Smart tracking startlight PSDW81642M-A360

In stock

SKU

PSDW81642M-A360

Rating:

100% of 100

1 Review Add Your Review

$4,618.79

PAL/NTSC

Brand

Qty

PSDW81642M-A360

8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera

> Panoramic: Eight 1/1.8'' 2 Megapixel progressive scan CMOS
> PTZ: One 1/1.8'' 4 Megapixel progressive scan CMOS
> Support 360-degree panoramic view
> Starlight technology
> H.265/H.264 triple-stream encoding
> Day/Night (ICR); 3D DNR; AWB; AGC; BLC
> IR distance up to 400 m
> Smart tracking
> Tripwire
> Intrusion
> Crowd map

> without Logo,English firmware
> 100% original products manufactured by DAHUA

Special Note:

Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

Skip to the end of the images gallery

Skip to the beginning of the images gallery

PSDW81642M-A360 - DAHUA 8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera With 360-degree panoramic view IR distance up to 400 m Smart tracking startlight PSDW81642M-A360

PSDW81642M-A360

8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera

> ,English firmware
> 100% original products manufactured by DAHUA

PSDW81642M-A360 - DAHUA 8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera With 360-degree panoramic view IR distance up to 400 m Smart tracking startlight PSDW81642M-A360 System Overview

Starlight panoramic HD network camera, with all-in-one design, provides a 360°panorama and region of interest details at the same time. The panoramic network combines 8 sensors working in tandem to realize 360°panoramic surveillance; all-in-one module and high-speed PTZ camera provides the function of quick position details. In addition, with video analytic algorithm and multi-target track algorithm, the camera can automatically or manually detect tripwire and intrusion of mutiple targets in detection area, output alarm signal, and then link PTZ for smart tracking. With these excellent features, the camera can meet higher security requirements.

DAHUA DH-PSDW81642M-A360

PSDW81642M-A360 - DAHUA 8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera With 360-degree panoramic view IR distance up to 400 m Smart tracking startlight PSDW81642M-A360 Functions

True Day/Night

A day/night mechanical IR cut filter makes this camera ideal for applications with fluctuating lighting conditions, delivering color images during the day and automatically switching to monochrome as the scene darkens.

Starlight Technology

Featured with Dahua Starlight Technology, the camera is ideal for applications with challenging light conditions. Its low light performance delivers usable video with minimal ambient light. Even in extreme low light conditions, Starlight Technology is capable of delivering color images in nearly complete darkness.

Crowd map

1. The crowd map is displayed on panorama. 2. Customized ROIs setting, people counting overlay and people thresh old alarm. 3. Global crowd density threshold setting and alarm. 4. Alarm linkage for global crowd density threshold and area people threshold (Arm period, record, sending E-mail and snapshot).

Tripwire detection and intrusion detection

With advanced CNN algorithm, the detection distance,and the accuracy rate and timely rate of linkage track are much improved.

Smart tracking

1. Panoramic channel supports manual position, frame selection zoom position.

2. Manual track.

3. Auto track after tripwire and intrusion are triggered.

4. Smart tracking after crowd map alarm is triggered.

DAHUA DH-PSDW81642M-A360

PSDW81642M-A360 - DAHUA 8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera With 360-degree panoramic view IR distance up to 400 m Smart tracking startlight PSDW81642M-A360 Picture

PSDW81642M-A360 - DAHUA 8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera With 360-degree panoramic view IR distance up to 400 m Smart tracking startlight PSDW81642M-A360 Dimension

PSDW81642M-A360 - DAHUA 8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera With 360-degree panoramic view IR distance up to 400 m Smart tracking startlight PSDW81642M-A360 Installation

PSDW81642M-A360 - DAHUA 8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera With 360-degree panoramic view IR distance up to 400 m Smart tracking startlight PSDW81642M-A360 Specification

Technical Specifications

******

Camera

Image sensor

Panoramic network camera: 1/1.8”CMOS PTZ camera: 1/1.8”CMOS

Max. resolution

Panoramic network camera: 8192 × 1800

PTZ camera: 2560 × 1440

Scan

Progressive

Electronic shutter

Panoramic network camera: 1/3 s-1/100000 s, manual or auto adjust

PTZ Camera: 1/1 s-1/300000 s, manual or auto adjust

Minimum illumination

Panoramic network camera:

0.01 Lux @ F2.0

PTZ camera:

0. 0008 Lux @ F1.3

Max fill light distance

Panoramic network camera: None PTZ camera: ≥ 400 m (1312 ft) (IR fill light)

Fill light control

Auto

Fill light quantity

Panoramic network camera：None PTZ camera: 7 (IR LEDs)

Lens angle range

N/A

Lens

Lens type

Panoramic network camera:
Fix focal PTZ camera: Electric zoom

Lens connector

Panoramic network camera ：M12 PTZ camera: Core interface

Focal length

Panoramic network camera 5 mm PTZ camera: 5.6mm–223mm, optical zoom (40 times)

Aperture

Panoramic network camera: F2.0 PTZ camera: F1.3

Angle of view

Panoramic network camera:Horizontal: 360° Vertical: 84° PTZ camera:Horizontal: 2°–61°

vertical: 1°-36°

Diagonal: 3°–68°

Optical zoom

Panoramic network camera: None PTZ camera: 40 times

Aperture type

Panoramic network camera: Fixed aperture PTZ camera: Auto aperture

Min photographic distance

Panoramic network camera :1.2 m (3.94 ft)

PTZ camera: 0.5 m (1.64 ft)

DORI distance

Detect

Observe

Reconize

Identify

Panoramic network camera

53.3m

( 174.9ft )

21.3m

( 69.9ft )

10.7m

( 35.1ft )

5.3m

( 17.4ft )

PTZ camera

2873.1m

( 9426.2ft )

1149.2m

( 3770.3ft )

574.6m

(1885.2ft)

287.3m

( 942.6ft )

Smart event

IVS analyze

Intrusion, tripwire

Professional, Intelligent

Crowd map

Crowd map, Global setup and No. in area

Video

Video encoding

H.265; H.264; H.264H; H.264B; MJPEG

Intelligent code

H.264

H.265

Video frame rate

Main stream: 8192 × 1800 (1–25 fps/30 fps)

Sub Stream: 3840 × 832 (1–25 fps/30 fps)

Third Stream: 4800x × 3840 (1–25 fps/30 fps)

Decoding

3 Streams

Resolution

Panoramic network camera:

8192 × 1800; 7680 × 1680; 5760 × 1264; 4800 × 3840; 4096 × 900; 3840 × 832; 3200 × 2560; 2560 × 560; 2048 × 452; 1600 × 1280

PTZ camera:

2560 × 1440; 2048 × 1536; 1920 × 1080; 1280 × 960

1280 × 720; 704 × 576; 704×480; 352 × 288; 352×240

Bit rate control

Panoramic network camera: CBR/VBR

PTZ camera:CBR/VBR

Video bit rate

Panoramic network camera:

H.264: 512 Kbps-42995 Kbps

H.265: 256 Kbps-26216 Kbps PTZ camera:

H.264: 184 Kbps-15104 Kbps

H.265: 110 Kbps-9216 Kbps

Day/Night

ICR

BLC

Yes

Wide dynamic range

120 dB

White balance

Panoramic network camera:Auto/Natural/street lamp/outdoor/manual/regional Custom

PTZ camera: Auto/indoor/outdoor/tracking/manual/sodium lamp/natural/street lamp

Gain control

Auto/Manual

Noise reduction

3D DNR

Motion Detection

Disable/Enable

Region of interest

Panoramic network camera: Yes (4 areas) PTZ camera:Yes (4 areas)

Electronic image stabilization(EIS)

Panoramic network camera: — PZT camera: Yes

Smart IR

Panoramic network camera: — PTZ camera: Yes (Adjusted by user.)

Defog

Panoramic network camera: — PTZ camera: Yes

Digital zoom

Panoramic network camera: N/A PTZ camera: 16 times

Privacy masking

Panoramic network camera (Privacy masking): 4 areas PTZ camera (Privacy masking): 8 areas

Audio

Audio encoding

G.711Mu/G.711A/ G.726/ AAC/

Network

Ethernet

One 10/100/1000Mbps Ethernet port
One 1000M fiber port(optional)

Network protocol

HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/IPv6; SNMP; QoS; UPnP; NTP

Third party access

ONVIF (Profile G); CGI

Scene self-adaptation

Yes

Max user

20 (Total bandwidth: 80 M)

Storage

SD card, FTP (SFTP), NAS (NFS/SMB)

Browser

IE, Chrome, Firefox, Safari

Platform

EVS, NVR, M70, DSS

Certification

CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Port

RS-485 port

One (Bit rate: 1200 bps-115200 bps)

Audio input

2 channels (connecting terminal)

Audio output

2 channels (connecting terminal)

Alarm input

7 channels (Wet contact, and it supports potential 3V–5V and max current 0.5A.)

Alarm output

3 channels (Wet contact, and it supports max potential 30V DC, 1 A/max potential 50V AC, current 0.5 A.)

Analog output

1 channel CVBS BNC port

Power

Power supply

DC36V

Power consumption

< 84.4W

Environment

Operating temperature

-40°C to +70°C (-40°F to +158°F)

Operating humidity

≤95%

Storage temperature

-40°C to +70°C (-40°F to +158°F)/Less than 95% RH

Protection grade

IP66

Structure

Enclosure

Metal + Plastic

Dimensions

Φ383 mm × 389.8 mm (Φ1256.56 ft × 1279.8 ft)

Net weight

14.7 kg (32.41 lb)

Gross weight

19.8 kg (43.65 lb)

****

Icctvzone-wholesales DAHUA IP Cameras
Icctvzone IP surveillance
Icctvzone-wholesales DAHUA NVR

best price of DAHUA camera

***

More Information
Wired/Wireless	Wired
Outdoor use	Outdoor use
Focal Type	Motorized Zoom, Vari-Focal
Day/Night	Low light
Factor	Dome
Max Resolution	8 MP
