PFS4226-24GT-360 - DAHUA DH-PFS4226-24GT-360 24-Port PoE Gigabit Managed Switch

In stock

SKU

PFS4226-24GT-360

$2,580.00

PFS4226-24GT-360

24-Port PoE Gigabit Managed Switch

> Layer 2 network management PoE switch
> Support IEEE802.3af, IEEE802.3at standard
> Support Hi-PoE 60W
> Network Redundancy: STP/RSTP/MSTP
> Support IPv4/IPv6, and DHCP
> Network management based on SNMP
> Configuration: Web, Telnet, CLI Command
> QoS (IEEE802.1p/1Q), CoS/ToS to Increase Determinism
> Enhanced Network Security with IEEE802.1X, SNMP v1/v2c/v3, HTTPS, and SSH/SSL
> Large data cache(4M), real-time transmission
> MAC auto study and aging, MAC address list capacity is 8K

> EMC high protection design

Special Note:

Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

Skip to the end of the images gallery

Skip to the beginning of the images gallery

PFS4226-24GT-360 - DAHUA DH-PFS4226-24GT-360 24-Port PoE Gigabit Managed Switch

PFS4226-24GT-360

24-Port PoE Gigabit Managed Switch

> EMC high protection design

PFS4226-24GT-360 - DAHUA DH-PFS4226-24GT-360 24-Port PoE Gigabit Managed Switch Picture

PFS4226-24GT-360 - DAHUA DH-PFS4226-24GT-360 24-Port PoE Gigabit Managed Switch Dimension

PFS4226-24GT-360 - DAHUA DH-PFS4226-24GT-360 24-Port PoE Gigabit Managed Switch Specification

*************

Technical Speciﬁcation
Model	DH-PFS4226-24GT-360
Ethernet Port	2410/100/1000 Base-T (PoE power supply) 2100/1000 Base-X
RS232 Serial Console	1*RS232 in RJ45 connector with console cable, 115.2Kbps, 8,N,1
PoE Power Consumption	Port1 and port 2 support Hi-PoE 60W Each power ≤30W, Total≤360W
PoE Protocol	IEEE802.3af, IEEE802.3at, Hi-PoE
Switching Capacity	52Gbps
Packet Forwarding Rate	38.688Mpps
Packet Buffer Memory	4Mb
Application Humidity	5%~95%
Power	AC100-240V, 50/60Hz
Lightning Protection	Common Mode 2KV Differential Mode 1KV
Working Temperature	-10°C~55°C
Dimension(W×D×H)	440mm x300mm x44mm
Accessories
Model
PFT3950	1.25G 850nm,500m,LC, Multi-mode
PFT3960	1.25G 1310/1550nm,20km,LC, Single-mode
PFT3970	1.25G 1550/1310nm,20km,LC, Single-mode

Service Characteristics
System	Username / password: admin/admin
System	IP Address :192.168.1.110/24
PoE Budget	Total≤360W
MAC Table	8K
NTP	Support
DHCP	Support DHCP client/server
DHCP	Support DHCP snooping
VLAN	802.1Q Standard VLAN
Port Aggregation	Manual aggregation/LACP
Mirroring	Many-to-one port mirroring
Flow Control	Half-duplex based on back pressure type control; Full duplex based on PAUSE frame
Multicast	IGMP Snooping v1/v2/v3
Security Features	Users management, SSH, HTTPS, SNMP v1/v2/v3, ROMN, ACL, IP source guard, ARP inspection, 802.1x, loop protection
Spanning tree	Support STP/RSTP/MSTP
LLDP	Support
MAC Table	Support MAC address table configuration
QoS	Support QoS base on CoS/DPL/PCP/DEI Each port support 8 output queue Support port shaping Support port tag remarking Support QoS base on DSCP
System Maintenance	Support the configuration file upload/download Support the updated packet upload System log
Network Management	WEB(http protocol), serial, SNMP

************
