PFS3006-4ET-60 - DAHUA DH-PFS3006-4ET-60 6-Port 10/100Mbps Unmanaged Desktop Switch with 4 PoE Ports
PFS3006-4ET-60
6-Port 10/100Mbps Unmanaged Desktop Switch with 4 PoE Ports
> * The parameters and datasheets below can only be applied to V2.0 (version 2.0)
> Layer two commercial switch
> Supports IEEE802.3, IEEE802.3u, IEEE802.3ab and IEEE802.3x standards> MDI/MDIX self-adaptation
> RJ-45 port supports 10/100 Mbps self-adaptation, and confirms to 802.3at, and 802.3af power supply standards
> Port 1 supports Hi-PoE 60W power supply
> 250 m PoE power supply
> Wall mounting and mechanical anti-thef
> 53V DC power supply
> Supports PoE watchdog
6-Port 10/100Mbps Unmanaged Desktop Switch with 4 PoE Ports is a type of layer two commercial switch. It provides 4 10/100 Mbps Ethernet ports and 2 10/100 Mbps uplink ports. The product is equipped with two types of transmission modes (Extend Mode On/Extend Mode Off). It also supports PoE watchdog to avoid manually maintenance and device restart, which can realize the intelligent management and reduce the cost.
Intelligent PoE
Adopt PoE power consumption management strategy, and supply power to important ports first. When total power consumption exceeds the set threshold value of the system, power down the ports from large port number to small port number. Adopt smart detection to prevent outage. Supply power with ultra-wide power range, and adapt to IPC power consumption fluctuations in severe environment.
Hi-PoE 60W
(Orange Port) Besides IEEE802.3af and IEEE802.3at, orange port also supports maximum 60W output.
Long Distance PoE
Breaking the IEEE 100 m transmission limit, the device supports 250 m
long distance PoE transmission with a more flexible networking. All Metal Design With all metal design, the device has good heat dissipation, and can work in severe environments.
POE Watchdog
Adopt the PoE watchdog function to avoid manually maintenance and device restart, which can realize the intelligent management and reduce the cost
PFS3006-4ET-60 - DAHUA DH-PFS3006-4ET-60 6-Port 10/100Mbps Unmanaged Desktop Switch with 4 PoE Ports Picture
PFS3006-4ET-60 - DAHUA DH-PFS3006-4ET-60 6-Port 10/100Mbps Unmanaged Desktop Switch with 4 PoE Ports Dimension
PFS3006-4ET-60 - DAHUA DH-PFS3006-4ET-60 6-Port 10/100Mbps Unmanaged Desktop Switch with 4 PoE Ports Panels
PFS3006-4ET-60 - DAHUA DH-PFS3006-4ET-60 6-Port 10/100Mbps Unmanaged Desktop Switch with 4 PoE Ports Application
PFS3006-4ET-60 - DAHUA DH-PFS3006-4ET-60 6-Port 10/100Mbps Unmanaged Desktop Switch with 4 PoE Ports Specification
*************
Technical Specification |
|
Model |
DH-PFS4226-24GT-360 |
Ethernet Port |
24*10/100/1000 Base-T (PoE power supply) 2*100/1000 Base-X |
RS232 Serial Console |
1*RS232 in RJ45 connector with console cable, 115.2Kbps, 8,N,1 |
PoE Power Consumption |
Port1 and port 2 support Hi-PoE 60W Each power ≤30W, Total≤360W |
PoE Protocol |
IEEE802.3af, IEEE802.3at, Hi-PoE |
Switching Capacity |
52Gbps |
Packet Forwarding Rate |
38.688Mpps |
Packet Buffer Memory |
4Mb |
Application Humidity |
5%~95% |
Power |
AC100-240V, 50/60Hz |
Lightning Protection |
Common Mode 2KV Differential Mode 1KV |
Working Temperature |
-10°C~55°C |
Dimension(W×D×H) |
440mm x300mm x44mm |
Accessories |
|
Model |
|
PFT3950 |
1.25G 850nm,500m,LC, Multi-mode |
PFT3960 |
1.25G 1310/1550nm,20km,LC, Single-mode |
PFT3970 |
1.25G 1550/1310nm,20km,LC, Single-mode |
Service Characteristics |
|
System |
Username / password: admin/admin |
IP Address :192.168.1.110/24 |
|
PoE Budget |
Total≤360W |
MAC Table |
8K |
NTP |
Support |
DHCP |
Support DHCP client/server |
Support DHCP snooping |
|
VLAN |
802.1Q Standard VLAN |
Port Aggregation |
Manual aggregation/LACP |
Mirroring |
Many-to-one port mirroring |
Flow Control |
Half-duplex based on back pressure type control; Full duplex based on PAUSE frame |
Multicast |
IGMP Snooping v1/v2/v3 |
Security Features |
Users management, SSH, HTTPS, SNMP v1/v2/v3, ROMN, ACL, IP source guard, ARP inspection, 802.1x, loop protection |
Spanning tree |
Support STP/RSTP/MSTP |
LLDP |
Support |
MAC Table |
Support MAC address table configuration |
QoS |
Support QoS base on CoS/DPL/PCP/DEI Each port support 8 output queue Support port shaping Support port tag remarking Support QoS base on DSCP |
System Maintenance |
Support the configuration file upload/download Support the updated packet upload System log |
Network Management |
WEB(http protocol), serial, SNMP |
************
