NVR4416-4KS2/I - DAHUA DHI-NVR4416-4KS2/I 16 Channel 1.5U 4HDDs WizSense Network Video Recorder NVR4416-4KS2/I
NVR4416-4KS2/I
16 Channel 1.5U 4HDDs WizSense Network Video Recorder
> Access, storage or forwarding at 256 Mbps (160 Mbps when AI function enabled)
> Max. decoding capability: 10 × 1080p@30 fps. Supports adaptive decoding
> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus
> AI by Camera: Face detection and recognition, perimeter protection;SMD Plus; ANPR; people counting; stereo analysis; heat map
> Security baseline 2.1
DAHUA original firmware, Upgradable,2 year guarantee
NVR4416-4KS2/I - DAHUA DHI-NVR4416-4KS2/I 16 Channel 1.5U 4HDDs WizSense Network Video Recorder NVR4416-4KS2/I
NVR4416-4KS2/I
16 Channel 1.5U 4HDDs WizSense Network Video Recorder
> Access, storage or forwarding at 256 Mbps (160 Mbps when AI function enabled)
> Max. decoding capability: 10 × 1080p@30 fps. Supports adaptive decoding
> AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus
> AI by Camera: Face detection and recognition, perimeter protection;SMD Plus; ANPR; people counting; stereo analysis; heat map
> Security baseline 2.1
NVR4416-4KS2/I - DAHUA DHI-NVR4416-4KS2/I 16 Channel 1.5U 4HDDs WizSense Network Video Recorder NVR4416-4KS2/I SYSTEM OVERVIEW
.
Dahua NVR4000-4KS2 is introduced as the first Lite series NVR that supports for 4K and H.265 encoding technology with excellent performance at an affordable price. For applications where image details are highly required, it delivers the capability of 4K resolution processing. The NVR can be served as edge storage, central storage or backup storage with an intuitive shortcut operation menu for remote management and control. Due to its cost-effective and easy-to-install design, this NVR is ideal for a wide range of applications such as public safety, water conservancy, transportation, city centers, education, and financial institutions. The NVR is compatible with numerous third-party devices making it the perfect solution for surveillance systems that work independently of video management system (VMS). It features an open architecture that supports for multi-user access and is compatible with ONVIF 2.4 protocol, enabling interoperability with IP cameras
NVR4416-4KS2/I - DAHUA DHI-NVR4416-4KS2/I 16 Channel 1.5U 4HDDs WizSense Network Video Recorder NVR4416-4KS2/I FUNCTIONS
4K Resolution
4K resolution is a revolutionary breakthrough in image processing technology. 4K delivers four times the resolution of standard HDTV 1080p cameras and offers superior picture quality and image details. 4K resolution improves the clarity of a magnified scene to view or record crisp forensic video from large areas.
Smart H.265+
Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ technology reduces bit rate and storage requirements by up to 70% when compared to standard H.265 video compression.
Face Detection
Face detection is to detect if there is any human face appearing in the video. This technology adopts a deep learning algorithm to support face detection, tracking, optimization and capturing, and then output the best face snapshot.
Face Recognition
Dahua Face Recognition technology extracts the features of captured faces and compares them with those in face database to recognize the person identity.
Perimeter Protection
Automatically filtering out false alarms caused by animals, rustling leaves, bright lights, etc. Enables system to perform secondary recognition for the targets. Improving alarm accuracy.
SMD Plus
With intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and filter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm.
AI Search
Support AI seach by metadata of different targets or uploading face pictures to device and comparing them with recorded faces by similarity. Enable operators to quickly and easily search through multi channels and long duration, efficiently find out when and where a person of interest appeard.
Smart Fan
The NVR is equipped with a smart fan to achieve high cooling efficiency. It automatically turns on or turns off according to CPU and ambient temperature. The fan is long-lasting and low noise, reducing maintenance costs and improving the user experience.
DMSS
The DMSS app is available on the iOS App Store and Google Play. It makes surveillance easy and simple, allowing you to remotely access NVR devices, view live video, receive event push notifications, and search for recorded videos from an iPhone, iPad, or Android phone at anytime from virtually anywhere!
.
NVR4416-4KS2/I - DAHUA DHI-NVR4416-4KS2/I 16 Channel 1.5U 4HDDs WizSense Network Video Recorder NVR4416-4KS2/I PICTURE
NVR4416-4KS2/I - DAHUA DHI-NVR4416-4KS2/I 16 Channel 1.5U 4HDDs WizSense Network Video Recorder NVR4416-4KS2/I DIMENSIONS
NVR4416-4KS2/I - DAHUA DHI-NVR4416-4KS2/I 16 Channel 1.5U 4HDDs WizSense Network Video Recorder NVR4416-4KS2/I REAR PANEL
NVR4416-4KS2/I - DAHUA DHI-NVR4416-4KS2/I 16 Channel 1.5U 4HDDs WizSense Network Video Recorder NVR4416-4KS2/I TECHNICAL SPECIFICATIONS
*******
|
System |
|
|
Main Processor |
Industrial-grade embedded processor |
|
Operating System |
Embedded Linux |
|
Operation Interface |
Web; local GUI |
|
AI |
|
|
AI by Camera |
Face detection; face recognition; perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map |
|
AI by Device |
Face detection; face recognition; perimeter protection; SMD Plus |
|
Perimeter Protection |
|
|
Perimeter Performance AI by Device(Number of Channels) |
2 |
|
Perimeter Performance of AI by Camera (Number of Channels) |
8 |
|
Face Detection |
|
|
Face Attributes |
6 attibutes: Gender; age group (6); glasses; expressions (8); mouth mask; beard |
|
Face Detection Performance of AI by Device (1080P) (Number of Channels) |
1 (up to 12 face images/second) |
|
Face Detection Performance of AI by Camera (Number of Channels) |
8 |
|
Face Recognition |
|
|
Face Database Capacity |
Up to 10 face databases with 20,000 images |
|
Face Recognition Performance of AI by Device (1080P) (Number of Channels) |
1 (up to 4 face images/second) |
|
Face Recognition Performance of AI by Camera (Number of Channels) |
8 |
|
SMD Plus |
|
|
SMD Plus by Device |
4 |
|
SMD Plus by Camera |
16-channel SMD Plus (AI by camera): Detects tripwire and intrustion of human or vehicle; filters false alarms caused by leaves, raindrops and change of brightness away |
|
ANPR |
|
|
ANPR by Camera |
4 |
|
Video |
|
|
Access Channel |
16 channels |
|
Network Bandwidth |
AI off: Access: 256 Mbps; Storage: 256 Mbps; Forward: 256 Mbps |
|
Resolution |
16MP; 12MP; 8MP; 5MP; 4MP; 3MP; 2MP; 720p; D1 |
|
Decoding Capability |
AI off: 1 channel × 16MP@20 fps; 1 channel × 12MP@20 fps; 2 channels × 8MP@30 fps; 4 channels × 5MP@30 fps; 5 channels × 4MP@30 fps; 10 channels × 1080p@30 fps |
|
Video Output |
1-ch VGA output and 1-ch HDMI output; simultaneous/heterogeneous video sources output for VGA and HDMI is configurable |
|
Multi-screen Display |
1st Screen: 1/4/8/9/16 |
|
Third Party Camera Access |
Panasonic; Sony; Samsung; Axis, Pelco; Arecont; ONVIF; Canon; RTSP |
|
Compression |
|
|
Video |
Smart H.265+; Smart H.264+; H.265; H.264; MJPEG |
|
Audio |
PCM; G.711A; G.711U; G.726 |
|
Network |
|
|
Network Protocol |
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register |
|
Mobile Phone Access |
Android; iOS |
|
Interoperability |
ONVIF(profile T/S/G); CGI; SDK |
|
Browser |
Chrome; IE9 or later; firefox |
|
Record Playback |
|
|
Multi-channel Playback |
Up to 16 channels |
|
Record Mode |
Manual; schedule (general; MD; alarm; MD & alarm; intelligent) |
|
Storage Method |
Local HDD; network |
|
Backup |
USB device |
|
Playback Function |
1. Play; pause; stop; fast forward; fast backward; rewind; play by frame |
|
Alarm |
|
|
General Alarm |
Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm |
|
Anomaly Alarm |
Camera disconnection; storage error; disk full; IP conflict; MAC conflict; login locked; and cybersecurity exception |
|
Intelligent Alarm |
Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map |
|
Alarm Linkage |
Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email |
|
External Port |
|
|
HDD |
4 SATA ports, up to 10 TB. The maximum HDD capacity varies with environment temperature |
|
USB |
1 front USB 2.0 port, 1 rear USB 3.0 port |
|
HDMI |
1 (max. resolution: 4K) |
|
VGA |
1 |
|
Network |
2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet ports |
|
RCA Input |
1 |
|
RCA Output |
1 |
|
Alarm Input |
16 |
|
Alarm Output |
4 |
|
RS-232 |
1 channel, used to debug and pass through serial data |
|
RS-485 |
1 channel, used to control PTZ, and it supports multiple protocols |
|
General Parameter |
|
|
Power Supply |
Single, 100 V–240 V AC, 50 Hz–60 Hz |
|
Power Consumption |
Total output of NVR is ≤ 8 W (without HDD) |
|
Net Weight |
4.25 kg (9.35 lb) |
|
Gross Weight |
6.48 kg (18.41 lb) |
|
Product Dimensions |
440.0 mm × 415.6 mm x 76.0 mm (17.32" × 16.36" × 2.99") (W × L × H) |
|
Package Dimensions |
529.0 mm × 499.0 mm × 211.0 mm (20.83" × 19.65" × 9.31") (W × L × H) |
|
Operating Conditions |
–10 °C to +55 °C (+10 °F to +131 °F) |
|
Storage Conditions |
0 °C to +40 °C (32 °F to 104 °F) |
|
Operating Humidity |
10%–93% |
|
Storage Humidity |
30%–85% |
|
Operating Altitude |
3,000 m (9,843 ft) |
|
Installation |
Desktop/Rack mount |
|
Certifications |
FCC:47 CFR FCC Part15,SubpartB,Class A |
**********
*
