NVR2104-P-4KS2 - DAHUA DHI-NVR2104-P-4KS2 4 Channel Smart 1U 4PoE Lite 4K H.265 Network Video Recorder With Support IPC UPnP, 4PoE ports High Efficiency Video Coding (H.265) 4K Resolution NVR2104-P-4KS2

In stock

SKU

NVR2104-P-4KS2

$108.00

NVR2104-P-4KS2

4 Channel Smart 1U 4PoE Lite 4K H.265 Network Video Recorder

> H.265/H.264 codec decoding
> Max 80Mbps incoming bandwidth
> Up to 8Mp resolution preview&playback
> Up to 1ch@8MP/4ch@1080P decoding
> HDMI/VGA simultaneous video output
> Support IPC UPnP, 4PoE ports

>without Logo,English firmware

>100% original products manufactured by DAHUA

Special Note:

Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

Can upgrade DAHUA original firmware,2 year guarantee

Skip to the end of the images gallery

Skip to the beginning of the images gallery

NVR2104-P-4KS2 - DAHUA DHI-NVR2104-P-4KS2 4 Channel Smart 1U 4PoE Lite 4K H.265 Network Video Recorder With Support IPC UPnP, 4PoE ports High Efficiency Video Coding (H.265) 4K Resolution NVR2104-P-4KS2 without logo

NVR2104-P-4KS2

4 Channel Smart 1U 4PoE Lite 4K H.265 Network Video Recorder

>without Logo,English firmware

>100% original products manufactured by DAHUA

NVR2104-P-4KS2 - DAHUA DHI-NVR2104-P-4KS2 4 Channel Smart 1U 4PoE Lite 4K H.265 Network Video Recorder With Support IPC UPnP, 4PoE ports High Efficiency Video Coding (H.265) 4K Resolution NVR2104-P-4KS2 without logo SYSTEM OVERVIEW

DAHUA NVR NEW UI 4.0

NVR2000-4KS2 is capable of transmitting 8MP image. It helps to save up to 50% HDD and storage space with its H.265 decoding technology compared with H.264. Due to its cost-effective and easy-to-install design, this NVR is ideal for a wide range of applications such as home safety, grocery, warehouse, education, and financial institutions. The NVR is compatible with numerous third-party devices making it the perfect solution for surveillance systems that work independently of video management system (VMS). It features an open architecture that supports for multi-user access and is compatible with ONVIF 2.4 protocol, enabling interoperability with IP cameras.

NVR2104-P-4KS2 - DAHUA DHI-NVR2104-P-4KS2 4 Channel Smart 1U 4PoE Lite 4K H.265 Network Video Recorder With Support IPC UPnP, 4PoE ports High Efficiency Video Coding (H.265) 4K Resolution NVR2104-P-4KS2 without logo FUNCTIONS

4K Resolution

4K resolution is a revolutionary breakthrough in image processing technology. 4K delivers four times the resolution of standard HDTV 1080p cameras and offers superior picture quality and image details. 4K resolution improves the clarity of a magnified scene to view or record crisp forensic video from large areas.

High Efficiency Video Coding (H.265)

The H.265 (ITU-T VCEG) video compression standard offers double the data compression ratio at the same level of video quality, or substantially improved video quality at the same bit rate, as compared to older video compression technologies. H.265 offers such impressive compression by expanding the pattern comparison and difference-coding, improving motion vector prediction and motion region merging, and incorporating an additional filtering step called sample-adaptive offset filtering.

Automatic Network Replenishment (ANR) Technology

Network Video Recorders with the ANR function automatically store video data on an IP camera SD card when the network is disconnected. After recovery of the network, the NVR automatically retrieves the video data stored on the camera.

Easy4ip

The Easy4ip app is available on the iOS App Store and Google Play. It makes surveillance easy and simple, allowing you to remotely access NVR devices, view live video, receive event push notifications, and search for recorded videos from an iPhone, iPad, or Android phone at anytime from virtually anywhere.

NVR2104-P-4KS2 - DAHUA DHI-NVR2104-P-4KS2 4 Channel Smart 1U 4PoE Lite 4K H.265 Network Video Recorder With Support IPC UPnP, 4PoE ports High Efficiency Video Coding (H.265) 4K Resolution NVR2104-P-4KS2 without logo PICTURE

NVR2104-P-4KS2 - DAHUA DHI-NVR2104-P-4KS2 4 Channel Smart 1U 4PoE Lite 4K H.265 Network Video Recorder With Support IPC UPnP, 4PoE ports High Efficiency Video Coding (H.265) 4K Resolution NVR2104-P-4KS2 without logo DIMENSIONS

NVR2104-P-4KS2 - DAHUA DHI-NVR2104-P-4KS2 4 Channel Smart 1U 4PoE Lite 4K H.265 Network Video Recorder With Support IPC UPnP, 4PoE ports High Efficiency Video Coding (H.265) 4K Resolution NVR2104-P-4KS2 without logo REAR PANEL

NVR2104-P-4KS2 - DAHUA DHI-NVR2104-P-4KS2 4 Channel Smart 1U 4PoE Lite 4K H.265 Network Video Recorder With Support IPC UPnP, 4PoE ports High Efficiency Video Coding (H.265) 4K Resolution NVR2104-P-4KS2 without logo TECHNICAL SPECIFICATIONS

******

System

Main Processor

Dual-core embedded processor

Operating System

Embedded LINUX

Audio and Video

IP Camera Input

4 Channel

Two-way Talk

1 Channel Input, 1 Channel Output, RCA

Display

Interface

1 HDMI, 1 VGA

Resolution

HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720

VGA: 1920×1080, 1280×1024, 1280×720

Decoding Capacity

1ch@8MP 30fps, 4ch@1080P 30fps

Multi-screen Display

1/4

OSD

Camera title, Time, Camera lock, Motion detection, Recording

Recording

Compression

H.265/H.264

Resolution

8MP/6MP/5MP/4MP/3MP/1080P/720P/D1&etc.

Record Rate

80Mbps

Bit Rate

16Kbps ~ 20Mbps Per Channel

Record Mode

Manual, Schedule(Regular(Continuous), MD, Stop

Record Interval

1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Video Detection and Alarm

Trigger Events

Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips

Video Detection

Motion Detection, MD Zones: 396 (22 × 18),

and Tampering

Alarm input

N/A

Relay Output

N/A

Playback and Backup

Sync Playback

1/4

Search Mode

Time /Date, MD and Exact Search

(accurate to second)

Playback Function

Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom

Backup Mode

USB Device/Network

Third-party Support

Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more

Network

Interface

1 RJ-45 port (10/100Mbps)

PoE

4 ports (IEEE802.3at/af)

Network Function

HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search(Support IP camera, DVR, NVS and etc.), Easy4ip

Optical Fiber Interface

N/A

Max. User Access

128 users

Smart Phone

iPhone, iPad, Android

Interoperability

ONVIF 2.4, SDK, CGI

Storage

Internal HDD

1 SATA III Port, up to 6TB capacity for each HDD

HDD Mode

Single

eSATA

N/A

Auxiliary Interface

USB

2 ports (2 Rear USB2.0)

RS232

N/A

RS485

N/A

Electrical

Power Supply

Single, DC48V/1.25A

Power Consumption

NVR: <5.3W (without HDD)

PoE: Max 25.5w for single port, 50w in total

Environmental

Operating Conditions

-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa

Storage Conditions

-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH

Construction

Dimensions(W×D×H)

Smart 1U, 204.6mm×204.6mm×45.6mm

(8.1" x 8.1" x 1.8")

Net Weight

0.45kg (0.99 lb) (without HDD)

Gross Weight

1.5kg(3.31 lb)(without HDD)

Certifications

EN55032, EN55024, EN50130-4, EN60950-1

FCC

Part 15 Subpart B, ANSI C63.4-2014

UL60950-1

******
