Camera

Image Sensor

1/1.8" CMOS

Max. Resolution

8192 (H) × 3840 (V)

ROM

8 GB

RAM

4 GB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

0.005 lux@F1.6 (Color,30 IRE)
0.0005 lux@F1.6 (B/W,30 IRE)
0 Lux (Illuminator on)

S/N Ratio

>56 dB

Illumination Distance

30 m (98.43 ft) (IR LED)

Illuminator On/Off Control

Auto; Manual

Illuminator Number

8 (IR LED)

Pan/Tilt/Rotation Range

Tilt: 0°–90°
Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Lens Mount

M16

Focal Length

2.8 mm

Max. Aperture

F1.6

Field of View

H: 180°; V: 100°

Iris Control

Fixed

Close Focus Distance

1.8 m (5.90 ft)

DORI Distance

Detect

Observe

Recognize

Identify

84.0 m

(275.59 ft)

33.6 m

(110.24 ft)

16.8 m

(55.12 ft)

8.4 m

(27.56 ft)

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (only supported
by the sub stream)

Smart Codec

Smart H.265+; Smart H.264+

Video Frame Rate

Main stream: 8192 × 3840@ (1–25/30 fps)
Sub stream: 1280 × 600@(1–25/30 fps)
Third stream: 2304 × 1080@(1–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Stream Capability

3 streams

Resolution

8192 × 3840; 7680 × 3600; 7168 × 3360; 6720 × 3152; 5760 ×2700; 4800 × 2252; 4096 × 1920; 2880 × 1360; 2304 × 1080; 2048× 960; 1520 × 712; 1280 × 600

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 96 kbps–23808 kbps
H.265: 38 kbps–14336 kbps

Day/Night

Auto(ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

DWDR

White Balance

Auto; natural; street lamp; outdoor; manual; regional custom

Gain Control

Auto; Manual

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

Yes (4 areas)

Privacy Masking

4 areas

Audio

Audio Compression

G.711a; G.711Mu; G.726; G.723; PCM

Alarm

Alarm Event

No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; scene changing; audio detection; voltage detection; external alarm; security exception

Network

Network Port

RJ-45 (10/100/1000 Base-T)

SDK and API

Yes

Network Protocol

IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP

Interoperability

ONVIF (Profile S/Profile GProfileT); CGI; Milestone; Genetec

User/Host

20

Storage

FTP; SFTP; Micro SD card (support max. 256 GB); NAS

Browser

IE: IE 9 and later
Chrome: Chrome 86 and later
Firefox: Firefox 86 and later

Management Software

Smart PSS; DSS; DMSS

Cyber Security

Configuration encryption;trusted execution; Digest; security logs; WSSE; account lockout; syslog; video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification

Certification

Certifications

CE-LVD:EN62368-1;
CE-EMC:Electromagnetic Compatibility Directive 2014/30/EU;
FCC:47 CFR FCC Part 15, Subpart B;
UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14

Port

RS-485

1 (baud rate range:1200 bps–115200 bps)

Audio Input

1 channel (RCA port)

Audio Output

1 channel (RCA port)

Alarm Input

2 channels in: 5 mA 3–5 VDC

Alarm Output

2 channels out: 1,000 mA 30 VDC/500 mA 50 VAC

Power

Power Supply

12 VDC/24 VAC/PoE+(802.3at)

Power Consumption

Basic power consumption: 10.6 W (12 VDC); 11.9 W(24 VAC); 11.9 W (PoE)
Max. power consumption (ICR + IR LED): 22.2 W (12 VDC); 25 W (24 VAC); 25 W (PoE)

Environment

Operating Temperature

–40 °C to +60 °C (–40 °F to +140 °F)

Operating Humidity

≤95%

Storage Temperature

–40 °C to +60 °C (–40 °F to +140 °F)

Protection

IK10; IP67

Structure

Casing Material

Metal + plastic

Product Dimensions

298.3 mm × 172.5 mm × 120.5 mm (11.74" × 6.79" × 4.74") (L × W × H)

Net Weight

3.16 kg (6.97 lb)

Gross Weight

4.06 kg (8.95 lb)
