Camera

Image Sensor

1/1.8”8Megapixel progressive CMOS

Effective Pixels

3840 (H) × 2160 (V)

ROM

4 GB

RAM

2 GB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100000 s

Min. Illumination

0.003 Lux@F1.2

IR Distance

Distance up to 60m (196.85 ft)

IR On/Off Control

Auto/Manual

IR LEDs Number

4 (IR LEDs)

Pan/Tilt/Rotation Range

Pan: 0°–360°

Tilt: 0°–90°

Rotation: 0°–360°

Lens

Lens Type

Motorized vari-focal

Mount Type

Module interface

Focal Length

2.7–12 mm

Max. Aperture

F1.2

Field of View

Horizontal: 114°(W)–47°(T)

Vertical: 59°(W)–27°(T)

Diagonal: 141° (W–55°(T)

Iris Type

Auto aperture

Close Focus Distance

W: 1 m (3.28ft)

T: 2.5 m (8.20ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

87.2 m (286.09 ft)

34.9 m (114.50 ft)

17.4 m (57.09 ft)

8.7 m

(28.54 ft)

T

186.7 m (612.53 ft)

74.7 m (245.07 ft)

37.3 m (122.38 ft)

18.6 m (61.02 ft)

Smart event

General IVS Analytics

Abandoned object, moving object

Professional, intelligent

Perimeter Protection

Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection

of vehicle and human); parking detection, loitering detection, and people gathering.

Face Detection

Face detection, track, priority, snapshot, face enhancement, face exposure, face attribute extract,

6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, sadness, disgust, fear,

surprise, calm, happiness and confusion), mask, beard Face matting setting: face, single inch photo T

hree snapshot methods: real-time snapshot, priority snapshot, quality priority

Face angle filter Priority time setting

ANPR

ANPR, track, priority, snapshot

Vehicle attributes: license plate, vehicle type, vehicle color,vehicle brand

Other attributes: sun visor, seat belt, smoking, phoning, in-car accessories, annual vehicle inspection mark

Video Metadata

Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes

extraction.

People Counting

People counting (count the entry number, exit number and pass number), display and output daily/monthly/annual statistics, No. in area

Intelligent Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.

Video

Video Compression

H.265, H.264,H.264H,H.264B, MJPEG

Smart Codec

Yes

Video Frame Rate

Main Stream: 3840 × 2160 (1–25/30 fps)
sub stream 1: 704 × 576 (1–25/30 fps)
sub stream 2: 1920 × 1080 (1–25/30 fps)
sub stream 3: 1920 × 1080 (1–25/30 fps)
sub stream 4: 704 × 576 (1–25/30 fps)

Stream Capability

5 streams

Resolution

8M (3840 × 2160), 6M (3072 × 2048/3072 × 1728), 5M (2592 × 1944), 4M (2688 × 1520), 3M (2048 ×

1536/2304 × 1296), 1080p(1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 ×

480), VGA (640 × 480), CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 32 kbps-16384 kbps

H.265: 12 kbps-16384 kbps

Day/Night

ICR switch

BLC

Yes

WDR

120 dB

White Balance

Auto/natural/street lamp/outdoor/manual/regional Custom

Gain Control

Auto/Manual

Noise Reduction

3DNR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest(RoI)

Yes (4 areas)

Electronic Image Stabilization(EIS)

Yes

Smart IR

Yes

Defog

Yes

Image Rotation

0°/90°/180°/270° (Supports 90°/270° with 1080p resolution or below.)

Mirror

Yes

Privacy Masking

4 areas

Audio

Audio Compression

G.711a; G.711Mu; G726; AAC; G.723

Network

Network

RJ-45 (10/100/1000 Base-T)

Protocol

HTTP; Https; 8021.x; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE;

IPv4/v6; SNMP; QoS; UPnP; NTP; SFTP; RTMP; Genetec;Bonjour

Interoperability

ONVIF (Profile S/Profile G/Profile T); CGI; P2P

Scene self-adaptation

Yes

User/Host

20

Edge Storage

FTP; Micro SD card (256 G); NAS; SFTP

Browser

IE: Versions later than IE9

Chrome: Versions later than Chrome 42 Firefox: Versions later than Firefox 48.0.2

Management Software

Smart PSS, DSS PRO, NVR, IVSS, DMSS

Mobile Phone

IOS, Android

Certification

Certifications

CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Port

RS-485

1 (Bit rate: 1200 bps-115200 bps)

Audio Input

Audio Interface: 1/1 channel In/Out

Audio Output

Alarm Input

3 channel In: 5mA 5V DC

2 channel Out: 1000mA 30V DC/500mA 50V AC

Alarm Output

Power

Power Supply

12V DC/24V AC/POE

Power Consumption

<17.3W

Environment

Operating Temperature

-40°C to +60°C (-40°F to +140°F)

Operating Humidity

≤95%

Storage Temperature

-40°C to +60°C (-40°F to +140°F)

Ingress Protection

IP67, IK10

Structure

Casing

Metal + Plastic

Dimensions

340.1 mm × 108.5 mm × 92.9 mm (13.39" × 4.27" × 3.66") (L × W × H)

Net Weight

1600g (3.53 lb)

Gross Weight

2400g (5.29 lb)
