IPC-HFW7442H-Z -DAHUA DH-IPC-HFW7442H-Z 4MP AI IR Bullet Starlight Network Camera With acurately detect person, vehicle, and non-motor vehicle, face, ANPR, and liveness functions IPC-HFW7442H-Z

In stock

SKU

IPC-HFW7442H-Z

Rating:

100% of 100

1 Review Add Your Review

$453.00

PAL/NTSC

Brand

Qty

IPC-HFW7442H-Z

4MP AI IR Bullet Network Camera

> 4MP, 1/1.8" CMOS image sensor, low illuminance,

high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/ night, 3D noise reduction, AWB, HLC, BLC

> ROI, SVC, SMART H.264/H.265, flexible coding,

applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting,

face detection, perimeter protection etc

> 24V AC/PoE/12V DC power support

> Five streams for three-channel HD video

> IP67, IK10 protection grade

>without Logo,English firmware
>100% original products manufactured by DAHUA

The delivery time is 15--25 working days

Special Note:

Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

Skip to the end of the images gallery

Skip to the beginning of the images gallery

IPC-HFW7442H-Z -DAHUA DH-IPC-HFW7442H-Z 4MP AI IR Bullet Starlight Network Camera With acurately detect person, vehicle, and non-motor vehicle, face, ANPR, and liveness functions IPC-HFW7442H-Z Without logo

IPC-HFW7442H-Z

4MP AI IR Bullet Network Camera

> 4MP, 1/1.8" CMOS image sensor, low illuminance,

high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/ night, 3D noise reduction, AWB, HLC, BLC

> ROI, SVC, SMART H.264/H.265, flexible coding,

applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting,

face detection, perimeter protection etc

> 24V AC/PoE/12V DC power support

> Five streams for three-channel HD video

> IP67, IK10 protection grade

>without Logo,English firmware
>100% original products manufactured by DAHUA

IPC-HFW7442H-Z -DAHUA DH-IPC-HFW7442H-Z 4MP AI IR Bullet Starlight Network Camera With acurately detect person, vehicle, and non-motor vehicle, face, ANPR, and liveness functions IPC-HFW7442H-Z Without logo System Overview

Ultra series product adopts high performance DSP and Sony advanced image sensor technology, which can provide excellent image effects for users such as UHD resolution, starlight and super WDR etc. The series utilizes Dahua advanced software algorithm, which is able to support people counting and heat map, bringing extra business analysis value for customers; IP67, IK10 and heater compliance enables the product to be applied in a more harsh environment.

IPC-HFW7442H-Z -DAHUA DH-IPC-HFW7442H-Z 4MP AI IR Bullet Starlight Network Camera With acurately detect person, vehicle, and non-motor vehicle, face, ANPR, and liveness functions IPC-HFW7442H-Z Without logo Functions

ePoE technology

The ePoE technology of Dahua, designed internally, adopts advanced 2D-PAM3 coding modulation from physical layer, and realizes full duplex transmission over 800 meters at the speed of 10Mbps, or 300 meters at the speed of 100Mbps via Cat 5 or coaxial cable media. Besides, it supports PoE and PoC power supply technology which has greatly simplified construction and wiring. Dahua ePoE technology offer a new way to accomplish long distance transmission between IP camera and network switch. It allows more flexible surveillance system design, improves reliability and saves construction and wiring cost.

Face Detection

Face Detection technology can detect the face in the image. With deep learning algorithm, the technology supports detecting, tracking, capturing and selecting the best face image, and then outputs face snapshot.

People Counting

With deep learning algorithm, Dahua People Counting technology can track and process moving human body targets to realize the accurate statistics of enter No., leave No., and In Area No. Working with management platform, it outputs yearly/monthly/weekly/daily reports to meet your requirements.

Video Metadata

With deep learning algorithm, Dahua Video Metadata technology can detect, track, capture vehicle, non-motor vehicle and people, and select the best images, and extract attributes.

Smart Codec

With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission.

Perimeter Protection

With deep learning algorithm, Dahua Perimeter Protection technology can recognize human and vehicle accurately. In restricted area (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast moving, parking detection, loitering detection and gathering detection) are largely reduced.

Privacy Protection

Privacy Protection technology can mask the detected face and human body to protect the privacy of some special targets.

IPC-HFW7442H-Z -DAHUA DH-IPC-HFW7442H-Z 4MP AI IR Bullet Starlight Network Camera With acurately detect person, vehicle, and non-motor vehicle, face, ANPR, and liveness functions IPC-HFW7442H-Z Without logo Picture

IPC-HFW7442H-Z -DAHUA DH-IPC-HFW7442H-Z 4MP AI IR Bullet Starlight Network Camera With acurately detect person, vehicle, and non-motor vehicle, face, ANPR, and liveness functions IPC-HFW7442H-Z Without logo Dimensions

IPC-HFW7442H-Z -DAHUA DH-IPC-HFW7442H-Z 4MP AI IR Bullet Starlight Network Camera With acurately detect person, vehicle, and non-motor vehicle, face, ANPR, and liveness functions IPC-HFW7442H-Z Without logo Installation

IPC-HFW7442H-Z -DAHUA DH-IPC-HFW7442H-Z 4MP AI IR Bullet Starlight Network Camera With acurately detect person, vehicle, and non-motor vehicle, face, ANPR, and liveness functions IPC-HFW7442H-Z Without logo

Technical Specifications

*****

Camera

Image Sensor

1/1.8” 4Megapixel progressive CMOS

Effective Pixels

2688 (H) × 1520 (V)

ROM

4 GB

RAM

2 GB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100000 s

Min. Illumination

0.001 Lux@F1.2

IR Distance

Distance up to 60m (196.85 ft)

IR On/Off Control

Auto/Manual

IR LEDs Number

4 (IR LEDs)

Pan/Tilt/Rotation Range

Pan: 0°–360°

Tilt: 0°–90°

Rotation: 0°–360°

Lens

Lens Type

Motorized vari-focal

Mount Type

Module interface

Focal Length

2.7–12 mm

Max. Aperture

F1.2

Field of View

Horizontal: 114°(W)–47°(T)

Vertical: 59°(W)–27°(T)

Diagonal: 141° (W–55°(T)

Iris Type

Auto aperture

Close Focus Distance

W: 1 m (3.28ft)

T: 2.5 m (8.20ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

60.1 m (187.19 ft)

24 m

(78.74 ft)

12 m

(39.37 ft)

6 m

(19.69 ft)

128.6 m (421.92 ft)

51.4 m (168.64 ft)

25.7 m (84.32 ft)

12.8 m (41.99 ft)

Smart event

General IVS Analytics

Abandoned object, moving object

Professional, intelligent

Perimeter Protection

Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection, loitering detection, and people gathering.

Face Detection

Face detection, track, priority, snapshot, face enhancement, face exposure, face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, sadness, disgust, fear, surprise, calm, happiness and confusion), mask, beard Face matting setting: face, single inch photo Three snapshot methods: real-time snapshot, priority snapshot, quality priority

Face angle filter Priority time setting

ANPR

ANPR, track, priority, snapshot

Vehicle attributes: license plate, vehicle type, vehicle color,vehicle brand

Other attributes: sun visor, seat belt, smoking, phoning, in-car accessories, annual vehicle inspection mark

Video Metadata

Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes extraction.

People Counting

People counting (count the entry number, exit number and pass number), display and output daily/monthly/annual statistics, No. in area

Intelligent Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.

Video

Video Compression

H.265, H.264, H.264H, H.264B, MJPEG

Smart Codec

Yes

Video Frame Rate

Main Stream: 2688 × 1520 (1–50/60 fps)
sub stream 1: 704 × 576 (1–25/30 fps)
sub stream 2: 1920 × 1080 (1–25/30 fps)
sub stream 3: 1920 × 1080 (1–25/30 fps)
sub stream 4: 704 × 576 (1–25/30 fps)

Stream Capability

5 streams

Resolution

4M (2688 × 1520), 3M (2304 × 1296), 1080p (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 32 kbps–10240 kbps

H.265: 12 kbps–10240 kbps

Day/Night

ICR switch

BLC

Yes

WDR

140 dB

White Balance

Auto/aatural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3DNR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest(RoI)

Yes (4 areas)

Electronic Image Stabilization(EIS)

Yes

Smart IR

Yes

Defog

Yes

Image Rotation

0°/90°/180°/270° (Supports 90°/270° with 1080p resolution or below.)

Mirror

Yes

Privacy Masking

4 areas

Audio

Audio Compression

G.711a; G.711Mu; G726; AAC; G.723

Network

RJ-45 (10/100/1000 Base-T)

Protocol

HTTP; Https; 8021.x; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP; QoS; UPnP; NTP; SFTP; RTMP; Genetec;Bonjour

Interoperability

ONVIF (Profile S/Profile G/Profile T); CGI; P2P

Scene self-adaptation

Yes

User/Host

Edge Storage

FTP; Micro SD card (256 G); NAS; SFTP

Browser

IE: Versions later than IE9

Google: Versions later than Chrome 42

Firefox: Versions later than Firefox 48.0.2

Management Software

Smart PSS, DSS PRO, NVR, IVSS, DMSS

Mobile Phone

IOS, Android

Certification

Certifications

CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Port

RS-485

1 (Bit rate: 1200 bps–115200 bps)

Audio Input

Audio Interface: 1/1 channel In/Out

Audio Output

Alarm Input

3 channel In: 5mA 5V DC

2 channel Out: 1000mA 30V DC/500mA 50V AC

Alarm Output

Power

Power Supply

12V DC/24V AC/POE

Power Consumption

<17.3W

Environment

Operating Temperature

-40°C to +60°C (-40°F to +140°F)

Operating Humidity

≤95%

Storage Temperature

-40°C to +60°C (-40°F to +140°F)

Ingress Protection

IP67, IK10

Structure

Casing

Metal + Plastic

Dimensions

340.1 mm × 108.5 mm × 92.9 mm (13.39" × 4.27" × 3.66") (L × W × H)

Net Weight

1600g (3.53 lb)

Gross Weight

2400g (5.29 lb)

**************

Icctvzone-wholesales DAHUA IP Cameras
Icctvzone IP surveillance
Icctvzone-wholesales DAHUA NVR

best price of DAHUA camera

More Information
Wired/Wireless	Wired
Outdoor use	Intdoor use, Outdoor use
Focal Type	Motorized Zoom
Day/Night	Low light
Factor	Bullet
Max Resolution	4 MP
