IPC-HFW71242H-Z - DAHUA DH-IPC-HFW71242H-Z 12MP IR Bullet WizMind Network Camera With Face Detection Perimeter Protection IPC-HFW71242H-Z

In stock

SKU

IPC-HFW71242H-Z

Rating:

100% of 100

4 Reviews Add Your Review

$456.00

IPC-HFW71242H-Z

12MP IR Bullet WizMind Network Camera

> 12MP 1/1.7” CMOS image sensor, high image definition

> Outputs max. 12MP (4000 × 3000) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in IR LED, max. IR distance: 60 m

> Rotation mode, DWDR; 3D NR, HLC, BLC, digital watermarking

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Perimeter Protection , Face Detection , Video Metadata , ANPR , People Counting , Queue Management

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply); 12V DC power output, max. current 165mA; easy for installation.

> IP67, IK10 protection

> Five streams for three-channel HD video

>without Logo,English upgradeable origianl firmware,

>100% original products manufactured by DAHUA

DAHUA IPC-HFW71242H-Z,DAHUA DH-IPC-HFW71242H-Z,IPC-HFW71242H-Z,DH-IPC-HFW71242H-Z,DH-IPC-HFW71242HP-Z,DH-IPC-HFW71242HN-Z,DAHUA 12MP Camera,DAHUA 12MP Bullet Camera,DAHUA 12MP Network Camera,DAHUA 12MP,DAHUA Camera 12mp

The delivery time is 15-25 working days

Special Note:

Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

Enough stock, welcome to order.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

IPC-HFW71242H-Z - DAHUA DH-IPC-HFW71242H-Z 12MP IR Bullet WizMind Network Camera With Face Detection Perimeter Protection IPC-HFW71242H-Z

IPC-HFW71242H-Z

12MP IR Bullet WizMind Network Camera

> 12MP 1/1.7” CMOS image sensor, high image definition

> Outputs max. 12MP (4000 × 3000) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in IR LED, max. IR distance: 60 m

> Rotation mode, DWDR; 3D NR, HLC, BLC, digital watermarking

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Perimeter Protection , Face Detection , Video Metadata , ANPR , People Counting , Queue Management

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply); 12V DC power output, max. current 165mA; easy for installation.

> IP67, IK10 protection

> Five streams for three-channel HD video

>,English upgradeable origianl firmware,

>100% original products manufactured by DAHUA

DH-IPC-HFW71242HP-Z,DH-IPC-HFW71242HN-Z,DAHUA 12MP Camera,DAHUA 12MP Bullet Camera,DAHUA 12MP Network Camera,DAHUA 12MP,DAHUA Camera 12mp

WizMind Series

WizMind is a wide range of project-oriented products that adopt industry-leading deep learning algorithms, such as IPC, NVR, PTZ, XVR, thermal camera and software platform. Focusing on customers’ needs, WizMind provides precise and reliable and comprehensive AI products for verticals.
Precise: Powered by AI chip and deep learning algorithms, WizMind delivers accurate detection and recognition of human and vehicle, enabling users to rapidly and precisely act on what really matters. In addition, it provides accurate and effective AI search to locate targets, and various human-based data for business analysis.
Reliable: Strict component selection to ensure the high product reliability. With thorough testing of front-end cameras, back-end device and platform, WizMind injects reliability into all of its solutions.
Comprehensive: Focusing on human and vehicle, WizMind provides various applications solutions such as face recognition, privacy protection, video metadata, stereo analysis, ANPR, illegal parking, etc. Moreover, WizMind combines deep learning algorithm with thermal imaging technology to help users achieve ultra-long distance monitoring in harsh environments, highly accurate non-contact temperature measurement with only ±0.3℃ temperature difference, and early detection of fire. wizmind AI

IPC-HFW71242H-Z - DAHUA DH-IPC-HFW71242H-Z 12MP IR Bullet WizMind Network Camera With Face Detection Perimeter Protection IPC-HFW71242H-Z System Overview

WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.

DAHUA Smart Shop solution

With advanced deep learning algorithm, Dahua WizMind 7 Series network camera supports various intelligent functions and satisfies the requirements in different scenes. The camera can accurately recognize person, vehicle, and non-motor vehicle, face, ANPR, and liveness. This series camera has ultra starlight night version effect, and works with ultra-low stream. It supports dust-proof function, waterproof function and vandal-proof function, complying with the standards of IP67 and IK10 (Supported by some select models).

IPC-HFW71242H-Z - DAHUA DH-IPC-HFW71242H-Z 12MP IR Bullet WizMind Network Camera With Face Detection Perimeter Protection IPC-HFW71242H-Z Functions

Video Metadata

With deep learning algorithm, Dahua Video Metadata technology can detect, track, capture vehicle, non-motor vehicle and people, and select the best images, and extract attributes.

Face Detection

Face Detection technology can detect the face in the image. With deep learning algorithm, the technology supports detecting, tracking, capturing and selecting the best face image, and then outputs face snapshot.

ANPR

With high-performance GPU chip, deep learning algorithm, and lots of sample training learning, Dahua ANPR technology can automatically collect and recognize the vehicle information, including license plate, logo, vehicle type, and vehicle color

Perimeter Protection

With deep learning algorithm, Dahua Perimeter Protection technology can recognize human and vehicle accurately. In restricted area (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast moving, parking detection, loitering detection and gathering detection) are largely reduced.

Smart H.265+ & Smart H.264+

With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission.

Perimeter Protection

With deep learning algorithm, Perimeter Protection technology can recognize human and vehicle accurately. In restricted area (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast moving, parking detection, loitering detection and gathering detection) are largely reduced.

Detect tripwire and intrusion violations Processing Flow

Protection (IP67, wide voltage)

IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.

IK10: The enclosure can stand the punch more than 5 times from a 5 kg hammer falling from a height of 40 cm (Impact energy is 20J). Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.

IPC-HFW71242H-Z - DAHUA DH-IPC-HFW71242H-Z 12MP IR Bullet WizMind Network Camera With Face Detection Perimeter Protection IPC-HFW71242H-Z Picture

IPC-HFW71242H-Z - DAHUA DH-IPC-HFW71242H-Z 12MP IR Bullet WizMind Network Camera With Face Detection Perimeter Protection IPC-HFW71242H-Z Dimensions

IPC-HFW71242H-Z - DAHUA DH-IPC-HFW71242H-Z 12MP IR Bullet WizMind Network Camera With Face Detection Perimeter Protection IPC-HFW71242H-Z Installation

IPC-HFW71242H-Z - DAHUA DH-IPC-HFW71242H-Z 12MP IR Bullet WizMind Network Camera With Face Detection Perimeter Protection IPC-HFW71242H-Z Technical Specifications

****

Camera
Image Sensor	1/1.7”12Megapixel progressive CMOS
Max. Resolution	4000 (H) × 3000 (V)
ROM	4 GB
RAM	2 GB
Scanning System	Progressive
Electronic Shutter Speed	Auto/Manual 1/3 s–1/100,000 s
Min. Illumination	0.01 Lux @F1.8
S/N Ratio	>56 dB
Illumination Distance	60m (196.9 ft) (IR LED)
Illuminator On/Off Control	Auto/Manual
Illuminator Number	4 (IR LED)
Pan/Tilt/Rotation Range	Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360°
Lens
Lens Type	Motorized vari-focal
Mount Type	φ14
Focal Length	2.7 mm-12 mm
Max. Aperture	F1.8
Field of View	Horizontal: 103°–44° Vertical: 75°–33° Diagonal: 135°–55°
Iris Type	Auto
Close Focus Distance	1.2 m (3.9 ft)
DORI Distance	Lens	Detect	Observe	Recognize	Identify
	W	93 m (305.1 ft)	37 m (121.4 ft)	18 m (59.1 ft)	9 m (29.5 ft)
	T	205 m (672.6 ft)	82 m (269.0 ft)	41 m (134.5 ft)	20 m (65.6 ft)
Smart event
IVS	Abandoned object; missing object
Professional, intelligent
IVS (Perimeter Protection)	Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection
Face Detection	Face detection; track; optimization; snapshot; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting; Support Duration Optimal,Non-living Filtering
People Counting	Support tripwire number counting, people counting in area, and displaying and outputting yearly/monthly/daily reports. Support queue management, and displaying and outputting monthly/daily reports. Support 4 tripwire rules configuration, people counting in 4 areas, and 4 queue management functions.
Video Metadata	Vehicle detection, non-motor vehicle detection, face detection, human body detection, track, optimization, snapshot, report high quality picture, vehicle attributes (license plate, vehicle type, vehicle color, and vehicle brand), other attributes (sun visor, seatbelt, smoking, phoning, in-car accessories, and annual vehicle inspection mark), non-motor vehicle attributes (vehicle type, vehicle color, hat, driver number, cloth type, and cloth color), personnel attribute (cloth type, trousers type, cloth color, trousers color, knapsack, hat, gender and umbrella), face attribute (gender, age, expression, glasses, mask, and beard)
Intelligent Search	Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Video Compression	H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec	Smart H.264+ Smart H.265+
Video Frame Rate	Main stream: 4000 × 3000 @1-25/30 fps Sub stream: 704 × 576@1-25fps, 704 × 480@1-30fps Third stream: 1920 × 1080 @1-25/30 fps Fourth stream: 1920 × 1080 @1-25/30 fps Fifth stream: 704 × 576 @1-25 fps; 704 × 480 @1-30 fps
Stream Capability	5 streams
Resolution	12M (4000 × 3000); 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728); 5M (2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536); 3M (2304 × 1296); 2M (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240); VGA (640 × 480)
Bit Rate Control	CBR/VBR
Video Bit Rate	H.264: 32 kbps–16384 kbps H.265: 32 kbps–14080 kbps
Day/Night	Auto (ICR)/Color/B/W
BLC	Yes
HLC	Yes
DWDR	Yes
White Balance	Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control	Auto/Manual
Noise Reduction	3D NR
Motion Detection	OFF/ON (4 areas, rectangular)
Region of Interest (RoI)	Yes (4 areas)
Smart Illumination	Yes
Defog	Yes
Image Rotation	0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower.)
Mirror	Yes
Privacy Masking	4 areas
Audio
Audio Compression	G.711A; G.711Mu; G.726; AAC; G.723
Alarm
Alarm Event	No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; defocus detection; external alarm; face detection; video metadata; ANPR; people counting in area; stay alarm; people counting; people counting exception detection; queue management;safety exception
Network
Network	RJ-45 (10/100/1000 Base-T)
SDK and API	Yes
Protocol	IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP; Bonjour
Interoperability	ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P;RTMP
User/Host	20 (Total bandwidth: 240 M.)
Storage	FTP; SFTP; Micro SD card (support max. 256 G); NAS;Dahua Cloud
Browser	IE: IE9 and later Chrome: Chrome 42 and later Firefox: Firefox 48.0.2 and later
Management Software	Smart PSS; DSS; DMSS
Mobile Phone	IOS; Android
Certification
Certifications	CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Port
RS-485	1 (baud rate range: 1200 bps–115200 bps)
Audio Input	1 channel (3.5mm JACK port)
Audio Output	1 channel (3.5mm JACK port)
Alarm Input	3 channels in: 5mA 3V–5V DC
Alarm Output	2 channels out: 1,000mA 30V DC/500mA 50V DC
Power
Power Supply	12V DC/24V AC/POE+(802.3at)
Power Consumption	<19.32W
Environment
Operating Conditions	–40°C to +60°C (–40°F to +140°F) /Less than 95% RH
Storage Conditions	–40°C to +60°C (–40°F to +140°F)
Protection Grade	IP67; IK10
Structure
Casing	Metal + plastic
Dimensions	340.1 mm × 138.3 mm × 134 mm (13.39" × 5.44" × 5.28") (L × W × H)
Net Weight	9.11 kg (20.08 lb)
Gross Weight	11.21 kg (24.71 lb)

***

Icctvzone-wholesales DAHUA IP Cameras

Icctvzone-wholesales DAHUA IP Cameras
Icctvzone IP surveillance
Icctvzone-wholesales DAHUA NVR

best price of DAHUA camera

*************************DAHUA IPC-HFW71242H-Z,DAHUA DH-IPC-HFW71242H-Z,IPC-HFW71242H-Z,DH-IPC-HFW71242H-Z,DH-IPC-HFW71242HP-Z,DH-IPC-HFW71242HN-Z,DAHUA 12MP Camera,DAHUA 12MP Bullet Camera,DAHUA 12MP Network Camera,DAHUA 12MP,DAHUA Camera 12mp*******************

More Information
Wired/Wireless	Wired
Outdoor use	Intdoor use, Outdoor use
Focal Type	Motorized Zoom
Day/Night	Low light
Factor	Bullet
Max Resolution	12 MP
