IPC-HFW2431TD-ZS-S2 – DAHUA DH-IPC-HFW2431TD-ZS-S2 4MP WDR IR Bullet Network Camera with 12V DC/PoE power 2.7~13.5mm varifocal lens Starlight IPC-HFW2431TD-ZS-S2 without logo

In stock
SKU
IPC-HFW2431TD-ZS-S2
$10,000.00

IPC-HFW2431TD-ZS-S2

4MP WDR IR Bullet Network Camera

> 4MP, 1/3” CMOS image sensor, low illuminance,
high image definition

> Outputs 4MP (2560 × 1440)@25/30 fps,
max. supports 4MP (2688 × 1520)@20 fps
> H.265 coding, high compression ration,
low bit rate

> Built-in IR LED, max IR distance: 60 m
> ROI, SMART H.264/H.265, flexible coding,
applicable to various bandwidth and storage
environments

> Rotation mode, WDR, 3D DNR, HLC, BLC,
digital watermarking, applicable to
various monitoring scenes

> Intelligent detection: Intrusion, tripwire
> Abnormality detection: Motion detection,
video tempering, no SD card, SD card full,
SD card error, network disconnected, IP conflict,
illegal access, voltage detection
> Max. 256 GB SD card
> 12V DC/POE power support
> IP67 protection ,IK10 protection (optional)

> without Logo,English firmware
> 100% original products manufactured by DAHUA

The delivery time is 25 working days.

Special Note:
Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

IPC-HFW2431TD-ZS-S2 – DAHUA DH-IPC-HFW2431TD-ZS-S2 4MP WDR IR Bullet Network Camera with 12V DC/PoE power 2.7~13.5mm varifocal lens Starlight IPC-HFW2431TD-ZS-S2 without logo

IPC-HFW2431TD-ZS-S2

4MP WDR IR Bullet Network Camera

> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition
> Outputs 4MP (2560 × 1440)@25/30 fps, max. supports 4MP (2688 × 1520)@20 fps
> H.265 coding, high compression ration, low bit rate
> Built-in IR LED, max IR distance: 60 m
> ROI, SMART H.264/H.265, flexible coding, applicable to various

bandwidth and storage environments
> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking,

applicable to various monitoring scenes
> Intelligent detection: Intrusion, tripwire
> Abnormality detection: Motion detection, video tempering, no SD card,

SD card full, SD card error, network disconnected, IP conflict,

illegal access, voltage detection
> Max. 256 GB SD card
> 12V DC/POE power support
> IP67 protection ,IK10 protection (optional)

> without Logo,English firmware
> 100% original products manufactured by DAHUA



IPC-HFW2431TD-ZS-S2 – DAHUA DH-IPC-HFW2431TD-ZS-S2 4MP WDR IR Bullet Network Camera with 12V DC/PoE power 2.7~13.5mm varifocal lens Starlight IPC-HFW2431TD-ZS-S2 without logo System Overview

With upgraded H.265 encoding technology, Dahua Lite series camera has efficient video encoding capacity, which saves bandwidth and storage space. This camera adopts the latest starlight technology and displays better colorful image in the environment of low illumination. It supports SD card storage, waterproof function, dust-proof function , complying to the standards of IP67.

DAHUA Smart Shop solution

IPC-HFW2431TD-ZS-S2 – DAHUA DH-IPC-HFW2431TD-ZS-S2 4MP WDR IR Bullet Network Camera with 12V DC/PoE power 2.7~13.5mm varifocal lens Starlight IPC-HFW2431TD-ZS-S2 without logo Functions

Smart Codec (H.265+ & H.264+)

Smart Codec is the optimized implementation of standard video compression (H.265 & H.264) that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart Codec technology reduces bit rate and storage requirements by up to 70% when compared to the standard video compression.

starlight

Starlight Technology

For challenging low-light applications, Dahua’s Starlight Ultra-low Light Technology offers best-in-class light sensitivity, capturing color details in low light down to 0.006lux. The camera uses a set of optical features to balance light throughout the scene, resulting in clear images in dark environments.

Intelligent Video analysis (IVS)

camera is equipped with a built-in intelligent analytic algorithm based on video, which can realize intelligent functions like Tripwire and Intrusion, to quickly and accurately respond to monitoring events in specific area, It can enhance monitoring efficiency. In addition, the camera supports intelligent tamper detection, which is to generate warning message via detecting dramatic scene change and to guarantee effective video surveillance.

Wide dynamic range (WDR)

adopts advanced Wide Dynamic Range (WDR) technology. You can get clear details in the environment of strong brightness contrast. In high brightness and back-light environment, bright region and dark region with strong light source, you can also get clear images.

Protection (IP67, wide voltage)

The camera allows for ±25% input voltage tolerance, suitable for the most unstable conditions for outdoor applications. Its 2KV lightning rating provides effective protection for both the camera and its structure against lightning. Subjected and certified to rigorous dust and immersion tests (IP67), the camera is the choice for installation in even the most unforgiving environments.

IPC-HFW2431TD-ZS-S2 – DAHUA DH-IPC-HFW2431TD-ZS-S2 4MP WDR IR Bullet Network Camera with 12V DC/PoE power 2.7~13.5mm varifocal lens Starlight IPC-HFW2431TD-ZS-S2 without logo Picture


IPC-HFW2231T-ZAS


IPC-HFW2431TD-ZS-S2 – DAHUA DH-IPC-HFW2431TD-ZS-S2 4MP WDR IR Bullet Network Camera with 12V DC/PoE power 2.7~13.5mm varifocal lens Starlight IPC-HFW2431TD-ZS-S2 without logo Dimension

IPC-HFW2231T-ZAS

IPC-HFW2431TD-ZS-S2 – DAHUA DH-IPC-HFW2431TD-ZS-S2 4MP WDR IR Bullet Network Camera with 12V DC/PoE power 2.7~13.5mm varifocal lens Starlight IPC-HFW2431TD-ZS-S2 without logo Installation



IPC-HFW2231T-ZAS

IPC-HFW2431TD-ZS-S2 – DAHUA DH-IPC-HFW2431TD-ZS-S2 4MP WDR IR Bullet Network Camera with 12V DC/PoE power 2.7~13.5mm varifocal lens Starlight IPC-HFW2431TD-ZS-S2 without logo Specification



Technical Specifications

****

Camera

Image Sensor

1/3” CMOS

Effective Pixels

2688 (H) × 1520 (V)

ROM

128 MB

RAM

128 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100000 s

Min. Illumination

0.01 Lux@F1.5

IR Distance

60 m (196.85 ft) (IR)

IR On/Off Control

Auto/Manual

IR LEDs Number

4 (IR LED)

Pan/Tilt/Rotation Range

Horizonal: 0°–360°
Vertical: 0°–90°
Rotation: 0°–360°

Lens

Lens Type

Motorized vari-focal

Mount Type

φ14

Focal Length

2.7 mm–13.5 mm

Max. Aperture

F1.5

Field of View

Horizonal: 104°–27°
Vertical: 55°–15°
Diagonal: 124°–31°

Optical Zoom

5 times

Iris Type

Fixed

Close Focus Distance

0.8m–0.8m (2.62 ft–2.62 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

64 m

(209.97 ft)

25.6 m

(83.99 ft)

12.8 m

(41.99 ft)

6.4 m

(21.00 ft)

T

220 m

(721.78 ft)

88 m

(288.71 ft)

44 m

(144.36 ft)

22 m

(72.18 ft)

Smart Event

General IVS Analytics

Intrusion; tripwire

Video

Video Compression

H.265; H.264; H.264B; MJPEG

Smart Codec

H.264: Yes
H.265: Yes

Video Frame Rate

50Hz
Main stream (2560 × 1440@25 fps); sub stream (704 × 576@25 fps)
Main stream (2688 × 1520@20 fps); sub stream (704 × 576@20 fps)
60Hz
Main stream (2560 × 1440@30 fps); sub stream (704 × 480@30 fps)
Main stream (2688 × 1520@20 fps); sub stream (704 × 480@20 fps)

Stream Capability

Main stream; sub stream

Resolution

2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 32 kbps–6144 kbps

H.265: 12 kbps–6144 kbps

Day/Night

ICR switch

BLC

Yes

WDR

120 dB

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

Disable/Enable (4 areas, rectangle)

Region of Interest(RoI)

Yes (4 areas)

Smart IR

Yes

Defog

Support

Image Rotation

0°/90°/180°/270° (Supports 90°/270° with 2688 ×1520 resolution.)

Mirror

Yes

Privacy Masking

4 areas

Network

Network

RJ-45 (10/100 Base-T)

Protocol

HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; QoS; UPnP; NTP; RTMP; Multicast; HTTPS; SFTP; 802.1x; ICMP; IGMP

Interoperability

ONVIF (Profile S/Profile G); CGI; Milestone; Genetec

User/Host

20

Edge Storage

Dahua Cloud; FTP; Micro SD card (max. 256 GB); NFS

Browser

IE
Google
Firefox

Management Software

Smart PSS; DSS; DMSS

Mobile Phone

IOS; Android

Certification

Certifications

CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Power

Power Supply

12V DC/POE

Power Consumption

Basic power consumption: 1.9W (12V DC), 2.8W (POE)

Max power consumption (H.265, Max resolution, Max stream, WDR, IR full intensity, IVS): 8W (12V DC), 9.6W (POE)

Environment

Operating Temperature

-30°C to +60°C (-22°F to +140°F)

Operating Humidity

≤95%

Storage Temperature

-40°C to +60°C (-40°F to +140°F)

Storage Humidity

≤95%

Protection

IP67;IK10(optional)

Structure

Casing

Metal

Dimensions

Φ244.1 mm × 90.4 mm (Φ9.61" × 3.26")

Net Weight

0.86 kg (1.90 lb)

Gross Weight

1.10 kg (2.43 lb)

*****

***

***

*****

**********

*************

*

*

Icctvzone-wholesales DAHUA IP Cameras
Icctvzone IP surveillance
Icctvzone-wholesales DAHUA NVR

best price of DAHUA camera

*

****

**********

More Information
Wired/Wireless Wired
Outdoor use Intdoor use, Outdoor use
Focal Type Vari-Focal
Day/Night D/N IR
Factor Bullet
Max Resolution 4 MP
