IPC-HFW2230S-S-S2 - DAHUA DH-IPC-HFW2230S-S-S2 2MP IR Bullet Network Camera With Supports max. 256 GB Micro SD card 12V DC/POE power support IP67 protection Intelligent detection IPC-HFW2230S-S-S2

In stock
SKU
IPC-HFW2230S-S-S2
$65.21

IPC-HFW2230S-S-S2

2MP IR Bullet Network Camera

> 2MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs 2MP (1920 × 1080)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in IR LED, max IR distance: 30 m

> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, DWDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire

> Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection

> Supports max. 256 GB Micro SD card

> 12V DC/POE power support

> IP67 protection

>DH Logo,English firmware
>100% original products manufactured by DAHUA

The delivery time is 25 working days usually, some times can complete early.

IPC-HFW2230S-S-S2 - DAHUA DH-IPC-HFW2230S-S-S2 2MP IR Bullet Network Camera With Supports max. 256 GB Micro SD card 12V DC/POE power support IP67 protection Intelligent detection IPC-HFW2230S-S-S2

IPC-HFW2230S-S-S2

2MP IR Bullet Network Camera

> 2MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs 2MP (1920 × 1080)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in IR LED, max IR distance: 30 m

> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, DWDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire

> Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection

> Supports max. 256 GB Micro SD card

> 12V DC/POE power support

> IP67 protection

>,English firmware
>100% original products manufactured by DAHUA

IPC-HFW2230S-S-S2 - DAHUA DH-IPC-HFW2230S-S-S2 2MP IR Bullet Network Camera With Supports max. 256 GB Micro SD card 12V DC/POE power support IP67 protection Intelligent detection IPC-HFW2230S-S-S2 System Overview



With upgraded H.265 encoding technology,  Lite series network camera has efficient video encoding capacity, which saves bandwidth and storage space. This camera adopts the latest starlight technology and displays better color image in the condition of low illumination. It supports SD card storage, dust-proof function, waterproof function and vandal-proof function, complying to the standards of IP67 and IK10 (Supported by some select models).

DAHUA Smart Shop solution

IPC-HFW2230S-S-S2 - DAHUA DH-IPC-HFW2230S-S-S2 2MP IR Bullet Network Camera With Supports max. 256 GB Micro SD card 12V DC/POE power support IP67 protection Intelligent detection IPC-HFW2230S-S-S2 Functions

Smart Codec

With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission.

WDR

With advanced Wide Dynamic Range (WDR) technology, Dahua network camera provides clear details in the environment of strong brightness contrast. The bright and dark area can get clear video even in high brightness environment or with backlight shadow.

Starlight

Starlight technology mainly applies to the environment of low illuminance, and it can provide clear colorful video. Even in the environment of ultra-low illuminance, the technology can guarantee the good image effect.

IVS

With advanced video algorithm, Dahua IVS technology supports intelligent functions, such as tripwire and intrusion.

Protection (IP67, wide voltage)

IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.



IPC-HFW2230S-S-S2 - DAHUA DH-IPC-HFW2230S-S-S2 2MP IR Bullet Network Camera With Supports max. 256 GB Micro SD card 12V DC/POE power support IP67 protection Intelligent detection IPC-HFW2230S-S-S2 Picture



DAHUA DH-IPC-HFW2231S-S-S2


IPC-HFW2230S-S-S2 - DAHUA DH-IPC-HFW2230S-S-S2 2MP IR Bullet Network Camera With Supports max. 256 GB Micro SD card 12V DC/POE power support IP67 protection Intelligent detection IPC-HFW2230S-S-S2  Dimensions

 DAHUA DH-IPC-HFW2231S-S-S2


IPC-HFW2230S-S-S2 - DAHUA DH-IPC-HFW2230S-S-S2 2MP IR Bullet Network Camera With Supports max. 256 GB Micro SD card 12V DC/POE power support IP67 protection Intelligent detection IPC-HFW2230S-S-S2  Installation


DAHUA DH-IPC-HFW2231S-S-S2

DAHUA DH-IPC-HFW2231S-S-S2

IPC-HFW2230S-S-S2 - DAHUA DH-IPC-HFW2230S-S-S2 2MP IR Bullet Network Camera With Supports max. 256 GB Micro SD card 12V DC/POE power support IP67 protection Intelligent detection IPC-HFW2230S-S-S2 Technical Specifications

*********

Camera

Image Sensor

1/2.7”2Megapixel progressive CMOS

Effective Pixels

1920 (H) × 1080 (V)

ROM

128 MB

RAM

128 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100000 s

Min. Illumination

0.005 Lux@F1.6

IR Distance

30 m (98.43 ft)

IR On/Off Control

Auto/Manual

IR LEDs Number

1

Pan/Tilt/Rotation Range

Horizonal: 0°–360°
Vertical: 0°–90°
Rotation: 0°–360°

Lens

Lens Type

Fixed

Mount Type

M12

Focal Length

2.8 mm
3.6 mm

Max. Aperture

F1.6
F1.6

Field of View

2.8 mm:
Horizonal: 110.0°
Vertical: 59.0°
Diagonal: 132.0°
3.6 mm:
Horizonal: 91.0°
Vertical: 48.0°
Diagonal: 109.0°

Iris Type

Fixed aperture

Close Focus Distance

2.8 mm: 0.6 m (1.97 ft)
3.6 mm: 1.1 m (3.61 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

37.3 m (122.38 ft)

14.9 m

(48.88 ft)

7.5 m

(24.61 ft)

3.7 m

(12.14 ft)

3.6 mm

53.3 m (174.87 ft)

21.3 m (96.88 ft)

10.7 m

(35.10 ft)

5.3 m

(17.39 ft)

Smart event

General IVS Analytics

Intrusion; tripwire

Video

Video Compression

H.265; H.264; H.264B; MJPEG

Smart Codec

Yes

Video Frame Rate

Main stream:

1920 × 1080 (1 fps-25/30 fps)

Sub stream:

704 × 576 (1 fps-25 fps)

704 × 480 (1 fps-30 fps)

Stream Capability

2 streams

Resolution

1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 32 Kbps–6144 Kbps
H.265: 12 Kbps–6144 Kbps

Day/Night

Auto(ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

DWDR

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest(RoI)

Yes (4 areas)

Smart IR

Yes

Image Rotation

0°/90°/180°/270° (Supports 90°/270° with 1080p resolution.)

Mirror

Yes

Privacy Masking

4 areas

Network

Network

RJ-45 (10/100 Base-T)

Protocol

IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour

Interoperability

ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec

User/Host

20

Edge Storage

 Cloud; FTP; SFTP; Micro SD Card (support max. 256 GB); NAS

Browser

IE
Chrome
Firefox

Management Software

Smart PSS; DSS; DMSS

Mobile Phone

IOS; Android

Certification

Certifications

CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Power

Power Supply

12V DC/PoE (802.3af)

Power Consumption

< 4.6W

Environment

Operating Conditions

-40°C to +60°C (-40°F to +140°F)/less than ≤ 95%

Storage Temperature

-40°C to +60°C (-40°F to +140°F)

Protection Grade

IP67

Structure

Casing

Metal

Dimensions

166.2 mm × Φ70 mm (6.54" × Φ2.76")

Net Weight

0.48 kg (1.1 lb)

Gross Weight

0.57 kg (1.3 lb)

************

**

Icctvzone-wholesales DAHUA IP Cameras
Icctvzone IP surveillance
Icctvzone-wholesales DAHUA NVR

best price of DAHUA camera

****

More Information
Wired/Wireless Wired
Outdoor use Intdoor use, Outdoor use
Focal Type Fixed
Day/Night Low light
Factor Bullet
Max Resolution 2 MP
