IPC-HF8630F-E – DAHUA DH-IPC-HF8630F-E 6MP Box Network Camera with H.265&H.264 triple-stream Business intelligent analysis (People counting, Heatmap) ePOE IPC-HF8630F-E without logo

IPC-HF8630F-E

6MP Box Network Camera

> 1/1.8” 6Megapixel progressive scan STARVIS™ CMOS
> H.265&H.264 triple-stream encoding
> 25/30fps@6M(3072×2048)
> DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> Auto back focus(ABF)
> Micro SD memory, PoE

>Excluding lens
> without Logo,English firmware
> 100% original products manufactured by DAHUA

IPC-HF8630F-E – DAHUA DH-IPC-HF8630F-E 6MP Box Network Camera with H.265&H.264 triple-stream Business intelligent analysis (People counting, Heatmap) ePOE IPC-HF8630F-E without logo  System Overview

Ultra series adopts high performance DSP and Sony advanced image sensor technology, which can provide excellent image effects for users. With Dahua advanced software algorithm, the series is able to support people counting and heat map which brings extra business analysis value for customers.

IPC-HF8630F-E – DAHUA DH-IPC-HF8630F-E 6MP Box Network Camera with H.265&H.264 triple-stream Business intelligent analysis (People counting, Heatmap) ePOE IPC-HF8630F-E without logo  Functions

ePoE technology

The ePoE technology of Dahua, designed internally, adopts advanced 2D-PAM3 coding modulation from physical layer, and realizes full duplex transmission over 800 meters at the speed of 10Mbps, or 300 meters at the speed of 100Mbps via Cat 5 or coaxial cable media. Besides, it supports PoE and PoC power supply technology which has greatly simplified construction and wiring. Dahua ePoE technology offer a new way to accomplish long distance transmission between IP camera and network switch. It allows more flexible surveillance system design, improves reliability and saves construction and wiring cost.

Business intelligent analysis (People counting, Heatmap)

Camera also supports more advanced intelligent features such as people counting and heat map besides basic IVS functions. These two functions can be applied to business intelligence and bring extra values to customers. It is available to acquire daily, weekly, monthly and yearly people flow via people counting and output data report. Heat map can be based on a moving object in time of space movement for analysis, find the most active area and output the report, which is to provide valuable data support for commercial applications.

HEVC (H.265)

HEVC (H.265) H.265 ITU-T VCEG is a new video coding standard. H.265 Following standard developed around the existing video coding standard H.264 , some retain the original technology , while some of the relevant technology to improve the new technology uses advanced technology to improve the relationship between the code stream , encoding quality , and the delay between algorithm complexity , optimize settings specific contents include : Improve compression efficiency , improve the robustness and error recovery capabilities, real-time to reduce the delay, reduce channel acquisition time and a random access delay , reduce complexity , etc

IPC-HF8630F-E – DAHUA DH-IPC-HF8630F-E 6MP Box Network Camera with H.265&H.264 triple-stream Business intelligent analysis (People counting, Heatmap) ePOE IPC-HF8630F-E without logo  Picture

IPC-HF8630F-E – DAHUA DH-IPC-HF8630F-E 6MP Box Network Camera with H.265&H.264 triple-stream Business intelligent analysis (People counting, Heatmap) ePOE IPC-HF8630F-E without logo  Dimension

IPC-HF8630F-E – DAHUA DH-IPC-HF8630F-E 6MP Box Network Camera with H.265&H.264 triple-stream Business intelligent analysis (People counting, Heatmap) ePOE IPC-HF8630F-E without logo  Installation
