Camera

Image Sensor

1/1.8” 2Megapixel progressive scan CMOS

Effective Pixels

1920(H)x1080(V)

RAM/ROM

2048MB/4096MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.002Lux/F1.53( Color,1/3s,30IRE)

0.01Lux/F1.53( Color,1/30s,30IRE)

0Lux/F1.53(IR on)

S/N Ratio

More than 50dB

IR Distance

Distance up to 100m(328ft)

IR On/Off Control

Auto/Manual

IR LEDs

3

Lens

Lens Type

Motorized

Mount Type

Board-in

Focal Length

8~32mm motorized

Max. Aperture

F1.53

Angle of View

H: 40°~12.9° V:22°~7.2°

Optical Zoom

4x

Focus Control

Motorized

Close Focus Distance

3m(9.84ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

106m(348ft)

42m(138ft)

21m(69ft)

10m(32ft)

T

320m(1050ft)

128m(420ft)

64m(210ft)

32m(105ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:0˚~355˚; Tilt:0˚~75˚; Rotation:0˚~355˚

Artificial Intelligence

Face Capture

Support face image capture

Face Attributes

Support 6 kinds of face attributes extraction: Age, Gender, Expression(Jolly, Calm, Surprise, Sad, Rage), Glasses, Mouth Mask, Moustache & Beard

Face Recognition

Support face images matching, support up to 10000 face images and 5 image libraries management;

Frame Rate

Main Stream: 1080P(1~50/60fps)

Sub Stream: D1 (1 ~ 50/60fps)

Third Stream: 1080P(1~50/60fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 24~ 10240Kbps

H.265: 14~ 6144Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR(120dB)/ SSA

White Balance

Auto/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization (EIS)

Support

Smart IR

N/A

Defog

Support

Digital Zoom

16x

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Camera

Image Sensor

1/1.8” 2Megapixel progressive scan CMOS

Effective Pixels

1920(H)x1080(V)

RAM/ROM

2048MB/4096MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.002Lux/F1.53( Color,1/3s,30IRE)

0.01Lux/F1.53( Color,1/30s,30IRE)

0Lux/F1.53(IR on)

S/N Ratio

More than 50dB

IR Distance

Distance up to 100m(328ft)

IR On/Off Control

Auto/Manual

IR LEDs

3

Lens

Lens Type

Motorized

Mount Type

Board-in

Focal Length

8~32mm motorized

Max. Aperture

F1.53

Angle of View

H: 40°~12.9° V:22°~7.2°

Optical Zoom

4x

Focus Control

Motorized

Close Focus Distance

3m(9.84ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

106m(348ft)

42m(138ft)

21m(69ft)

10m(32ft)

T

320m(1050ft)

128m(420ft)

64m(210ft)

32m(105ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:0˚~355˚; Tilt:0˚~75˚; Rotation:0˚~355˚

Artificial Intelligence

Face Capture

Support face image capture

Face Attributes

Support 6 kinds of face attributes extraction: Age, Gender, Expression(Jolly, Calm, Surprise, Sad, Rage), Glasses, Mouth Mask, Moustache & Beard

Face Recognition

Support face images matching, support up to 10000 face images and 5 image libraries management;

General Intelligence

Event Trigger

Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly

General Intelligence

Tripwire, Intrusion, Object Abandoned/Missing, People Counting, Heat Map

Video

Compression

H.265/H.264/H.264B/H.264H/MJPEG(sub stream)

Smart Codec

Support H.265+/H.264+

Streaming Capability

3 Streams

Resolution

1080P(1920×1080)/ 1.3M(1280x960)/ 720P(1280x720)/ D1(704×576/704x480)/ VGA(640x480)

Interface

Video Interface

1 Port(For adjustment only)

Audio Interface

1/1 channel In/Out

RS485

1 port

Alarm

1 channel In: 5mA 5VDC

1 channel Out: 1A 30VDC / 0.5A 50VAC

Electrical

Power Supply

DC12V, AC24V, PoE+(802.3at)(Class 4)

Power Consumption

DC12V:6.6W 15.84W(IR on)

PoE:6.1W 14W(IR on)

Environmental

Operating Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Storage Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

IK10

Construction

Casing

Metal

Dimensions

Φ159.1mm*117.9mm

Net Weight

0.99Kg (2.18lb)

Gross Weight

1.9Kg (4.19lb)

Camera

Image Sensor

1/1.8” 2Megapixel progressive scan CMOS

Effective Pixels

1920(H)x1080(V)

RAM/ROM

2048MB/4096MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.002Lux/F1.53( Color,1/3s,30IRE)

0.01Lux/F1.53( Color,1/30s,30IRE)

0Lux/F1.53(IR on)

S/N Ratio

More than 50dB

IR Distance

Distance up to 100m(328ft)

IR On/Off Control

Auto/Manual

IR LEDs

3

Lens

Lens Type

Motorized

Mount Type

Board-in

Focal Length

8~32mm motorized

Max. Aperture

F1.53

Angle of View

H: 40°~12.9° V:22°~7.2°

Optical Zoom

4x

Focus Control

Motorized

Close Focus Distance

3m(9.84ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

106m(348ft)

42m(138ft)

21m(69ft)

10m(32ft)

T

320m(1050ft)

128m(420ft)
