IPC-HDBW7842H-Z4 - DAHUA DH-IPC-HDBW7842H-Z4 8MP IR Dome WizMind Network Camera With People Counting Face Detection Perimeter Protection IPC-HDBW7842H-Z4

IPC-HDBW7842H-Z4

8MP IR Dome WizMind Network Camera

> 8MP, 1/1.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP(3840 × 2160) @25/30 fps

> H.264&H.265 coding, high compression ration

> WDR, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detection, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/PoE/12V DC power support

> Five streams for three-channel HD video

> IP67, IK10 protection

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation

IPC-HDBW7842H-Z4 - DAHUA DH-IPC-HDBW7842H-Z4 8MP IR Dome WizMind Network Camera With People Counting Face Detection Perimeter Protection IPC-HDBW7842H-Z4 System Overview

 WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.

With advanced deep learning algorithm, Dahua WizMind 7 Series network camera supports various intelligent functions and satisfies the requirements in different scenes. The camera can accurately recognize person, vehicle, and non-motor vehicle, face, ANPR, and liveness. This series camera has ultra starlight night version effect, and works with ultra-low stream. It supports dust-proof function, waterproof function and vandal-proof function, complying with the standards of IP67 and IK10 (Supported by some select models).

IPC-HDBW7842H-Z4 - DAHUA DH-IPC-HDBW7842H-Z4 8MP IR Dome WizMind Network Camera With People Counting Face Detection Perimeter Protection IPC-HDBW7842H-Z4 Functions

ePoE

ePoE technology provides a new way to accomplish long distance transmission between IP camera and network switch. It allows more flexible surveillance system design, improves reliability and saves construction and wiring cost.

Video Metadata

With deep learning algorithm, Dahua Video Metadata technology can detect, track, capture vehicle, non-motor vehicle and people, and select the best images, and extract attributes.

Face Detection
Dahua Face Detection technology can detect the face in the image. With
deep learning algorithm, the technology supports detecting, tracking,
capturing and selecting the best face image, and then outputs face
snapshot

People Counting
With deep learning algorithm, Dahua People Counting technology
can track and process moving human body targets to realize the
accurate statistics of enter No., leave No., and In Area No. Working with
management platform, it outputs reports to meet your requirements

Video Metadata
With deep learning algorithm, Dahua Video Metadata technology can
detect, track, capture vehicle, non-motor vehicle and people, and select
the best images, and extract attributes. The camera can count targets by
directions (A>B, B>A, or A< >B), and export the report

Face and Human Body Association
With deep learning algorithm, Dahua Face and Human Body Association
technology detects face and human body of one person, captures them
separatedly, selects the best image, and then associates them.
Face Recognition
Dahua Face Recognition technology extracts the features of captured
faces and compares them with that in face database to recognize the
person identity.
Advanced Customer Counter
With Advanced Customer Counter, the camera can remove staff and
returning customers from your store traffic count. It enables managers
to build a full picture of the number and groups of customers.
PPE Detection
With the PPE Detection function, the camera can detect attributes
includ ing face masks, helmets, glasses, safety vests, and the color of
tops and bottoms, and determine whether PPE requirements are met.
Match att ributes alarm or mismatch attributes alarm can be triggered
according to the alarm settings.

Smart H.265+ & Smart H.264+

With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission.

Perimeter Protection

With deep learning algorithm, Perimeter Protection technology can recognize human and vehicle accurately. In restricted area (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast moving, parking detection, loitering detection and gathering detection) are largely reduced.

ANPR
With high-performance GPU chip, deep learning algorithm, and lots of
sample training learning, Dahua ANPR technology can automatically
collect and recognize the vehicle information, including license plate,
logo, vehicle type, and vehicle color.
Cyber Security
Dahua network camera is equipped with a series of key security
technologies, such as security authentication and authorization, access
control, trusted protection, encrypted transmission, and encrypted
storage, which improve its security defense and data protection, and
prevent malicious programs from invading the device.
Queue Management
With advanced image processing technology and deep leaning
algorithm, Dahua Queue Management technology counts people
quantity in selected area in real time to realize queue management. It
supports multiple polygon areas. When No. in area/strand time is not
smaller or not larger than the threshold, it triggers alarm.

Protection (IP67, wide voltage)

IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.

IK10: The enclosure can stand the punch more than 5 times from a 5 kg hammer falling from a height of 40 cm (Impact energy is 20J). Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.

IPC-HDBW7842H-Z4 - DAHUA DH-IPC-HDBW7842H-Z4 8MP IR Dome WizMind Network Camera With People Counting Face Detection Perimeter Protection IPC-HDBW7842H-Z4 Picture

IPC-HDBW7842H-Z4 - DAHUA DH-IPC-HDBW7842H-Z4 8MP IR Dome WizMind Network Camera With People Counting Face Detection Perimeter Protection IPC-HDBW7842H-Z4  Dimensions

IPC-HDBW7842H-Z4 - DAHUA DH-IPC-HDBW7842H-Z4 8MP IR Dome WizMind Network Camera With People Counting Face Detection Perimeter Protection IPC-HDBW7842H-Z4  Installation
