Camera

Image Sensor

1/1.7" CMOS

Max. Resolution

3008 (H) × 3000 (V)

ROM

4 GB

RAM

2 GB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

0.01 lux (Color)

S/N Ratio

> 56 dB

Lens

Lens Type

Fixed-focal

Lens Mount

M12

Focal Length

1.85 mm

Max. Aperture

F2.0

Field of View

Horizontal: 180°; Vertical: 180°; Diagonal: 185°

Iris Control

Fixed

Close Focus Distance

0.4 m (1.31 ft)

DORI Distance

Detect

Observe

Recognize

Identify

40.0 m
(131.23 ft)

16.0 m
(52.49 ft)

8.0 m
(26.2 ft)

4.0 m
(13.12 ft)

Professional, intelligent

Parking Space Management (Fisheye)

Supports the mode of 12 parking spaces and 6 parking spaces

Video

Video Compression

H.265; H.264; H.264H; MJPEG (Only supported by the sub stream)

Smart Codec

Smart H.265+; Smart H.264+

Video Frame Rate

Main stream: 2432 × 2432@(1–20 fps )

sub stream: 704 × 576@(1–20 fps)/704×480 @(1–20 fps)

third stream: 3008 × 3000@(1–20 fps)

Stream Capability

3 streams

Resolution

3008 × 3000; 2432 × 2432; 2304 × 2304; 2144 × 2144; 1536 × 1536; 1.3M (1280 × 960); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H264: 8 kbps–16384 kbps
H265: 8 kbps–16384 kbps

Day/Night

Auto(ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

DWDR

White Balance

Auto; natural; street lamp; outdoor; manual; regional custom

Gain Control

Auto

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

Yes (4 areas)

Privacy Masking

4 areas

Alarm

Alarm Event

No SD card; SD card full; SD card durability warning; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; scene changing; audio detection; voltage detection; external alarm; security exception; (parking space) occupied; (parking space) available

Network

Network Port

RJ-45 (10/100/1000 Base-T)

SDK and API

Yes

Cyber Security

Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade

Network Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP

Interoperability

ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P

Storage

FTP; SFTP; Micro SD card (support max. 256 GB); NAS

Browser

With plug-in:
IE: IE 9 and later
Chrome: Chrome 86 and later
Firefox: Firefox 86 and later
Without plug-in:
Edge
Chrome: Chrome 86 and later
Firefox: Firefox 86 and later

Management Software

PMS

Certification

Certifications

CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B

Power

Power Supply

12 VDC/PoE+ (802.3at)

Power Consumption

Basic: 6.054 W (12 VDC); 5.893 W (PoE)
Max. (ICR + indicator intensity + power output): 8.845 W (12 VDC); 8.325 W (PoE)
Heating: 3 W (12 VDC); 3 W (PoE)

Environment

Operating Temperature

–30 °C to +45 °C (–22 °F to +113 °F)

Operating Humidity

≤ 95%

Storage Temperature

–30 °C to +70°C (–22 °F to +158 °F)

Protection

IP67

Structure

Casing

Metal + plastic

Product Dimensions

83.8 mm × Φ176 mm (3.3" × Φ6.9")

Net Weight

0.776 kg (1.71 lb)

Gross Weight

1.19 kg (2.62 lb)
