Hikvision DS-9664NI-I8 - Hikvision DS-9664NI-I8 64-ch 2U 4K NVR with Supports various special function cameras TECHNICAL SPECIFICATIONS

*********

Video And Audio

IP Video Input64-ch Up to 12 MP resolution

HDMI 1 OutputHDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60HzVGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,

HDMI 2 Output1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,2-ch, RCA (2.0Vp-p, 1 KΩ)

VGA OutputHDMI,VGA

CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480

Incoming Bandwidth320 Mbps or 200 Mbps (when RAID is enabled),256 Mbps, or 200 Mbps (when RAID is enabled)

Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)

Decoding

Decoding FormatH.265+,H.265,H.264+,H.264

Decoding Capability2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps)

Synchronous Playback16-ch

Recording Resolution12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Network

Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS

Remote Connection128

Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

PoE

InterfaceN/A

RAID

RAID Type4

Auxiliary Interface

SATA8

ESATA1 eSATA interface

CapacityUp to 10TB capacity for each HDD

Serial InterfaceRS-232; RS-485; Keyboard

USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0

Alarm In/Out16/4

General

Power Supply100 to 240 VAC, 50 to 60 Hz 200 W

Consumption≤ 30 W

Working Temperature-10 °C to 55 °C (14 °F to 131 °F)

Working Humidity10 to 90 %

Chassis2U

Dimension (W × D × H)445 × 470 ×90 mm (17.5"× 18.5" × 3.5")

Weight≤ 10 kg (22 lb)

***************

*
